Installing System Components 95
Figure 3-9. Removing and Installing an Optical or Tape Drive
1 optical drive 2 shoulder screws (3)
3 drive bay screw slots 4 drive release latch
5 power and data cables
5
1
2
4
3
book.book Page 95 Monday, June 15, 2009 11:33 AM
