Table 8. QSFP28 and unified QSFP28 port LEDs
LED Description
Solid greenLink operating at maximum speed100G for
QSFP28 port
Flashing greenLink activity operating at maximum speed
100G port
Solid yellowLink operating at a lower speed40G or
10G port
Flashing yellowPort activity at a lower speed40G or
10G port
Flashing yellow, 1 second on/offPort beacon
Table 9. QSFP28 and unified QSFP28 port LEDs: 4x25G or 4x10G mode
LED Description
Link/Activity LED
OffNo link
Solid greenLink operating at maximum speed4x25G
port
Flashing greenLink activity operating at maximum speed
4x25G port
Solid yellowLink operating at a lower speed4x10G port
Flashing yellowPort activity at a lower speed4x10G
port
Flashing yellow, 1 second on/offPort beacon
Table 10. QSFP28 and unified QSFP28 port LEDs: 2x50G mode
LED Description
Link/Activity LED
OffNo link
Solid yellowLink operating at a lower speed2x50G
port
Flashing yellowLink activity at a lower speed2x50G
port
Flashing yellow, 1 second on/offPort beacon
Table 11. QSFP+ port LEDs
LED Description
Link/Activity LED
OffNo link
Solid greenLink operating at maximum speed40G port
Flashing greenLink activity operating at maximum speed
40G port
Flashing yellow, 1 second on/offPort beacon
Table 12. QSFP+ port LEDs: 4x1G or 4x10G mode
LED Description
Link/Activity LED
OffNo link
Solid greenLink operating at maximum speed10G port
Flashing greenLink activity operating at maximum speed
10G port
Solid yellowLink operating at a lower speed1G port
Flashing yellowPort activity at a lower speed1G port
Flashing yellow, 1 second on/offPort beacon
16 S4100ON Series switch
