3–Adapter Management Applications
Windows Management Applications
89 CU0354602-00 L
To modify team composition:
1. On the Team Management page, in the left pane under Teams and
Adapters, right-click the team name whose properties are to be changed.
2. On the shortcut menu, click Modify Team (see Figure 3-11).
Figure 3-11. Modifying Team Properties
3. On the Modify Team Properties dialog box, change the team parameters
as needed and then click OK.
To ensure that the properties of all teamed adapters and adapters with
VLANs remain synchronized with the team properties, do not directly modify
the adapter properties on the Advanced page. If an adapter property
becomes unsynchronized with its team properties, change either the team or
adapter property so that they are the same on each and then reload the
team. To reload a team: On the Team Management page, in the left pane
under Teams and Adapters, right-click the team name and then click
Reload Team.
