The S4810 System | 11
To successfully install the S4810, ensure that you have the following:
• S4810 chassis (or multiple chassis, if stacking)
• At least one grounded AC power source per chassis
• Cable to connect the AC power source to the chassis (US power cables included)
• Mounting brackets for rack installation (included)
• Screws for rack installation and #1 and #2 Phillips screwdrivers (not included)
• Ground cable (not included)
• Ground cable screws (included)
• Copper/fiber cables
Other optional components are:
• Additional power supply unit
• Additional fan module
• Additional mounting brackets (if installing in a 4-post rack or cabinet)
Features
The S4810 offers the following:
• S4810 CPU and switch processor
• Up to six stacked units on FTOS 8.3.12.0 release; up to three stacked units on previous releases (not
supported on FTOS 8.3.8.x and 8.3.10.x)
• Stackable switch features (not supported on FTOS 8.3.8.x and 8.3.10.x)
10 Gig
SFP+ LRM 220 M (FDDI-
grade multi-
mode, OM1,
OM2, OM3)
N/A HMTNW
SFP+ SR 300 M GP-10GSFP-1S WTRD1
SFP+ LR 10K M GP-10GSFP-1L RN84N
1 Gig
SFP SR 550 M GP-SFP2-1S GF76J
SFP LR 10K M GP-SFP2-1Y J6FGD
Copper SFP 100 M GP-SFP2-1T VK6C4
QSFP+
Breakout
Cable
40GE QSFP+ to 4 SFP+
optical cable
5 M CBL-QSFP-4x10GSFP-5M 1X3JJ
SFP 40GE QSFP+ to 4
SFP+ passive breakout
cable
5 M CBL-QSFP-4x10GSFP-PASS-
5M
HVVVF
Table 2-2. Supported Optics (continued)
Optic Size Optic Type Reach (Meters) Force10 Catalog Number Dell Part Number
