14 Disassembly and reassembly
Next steps
1. Install the stand.
2. Follow the procedure in After working inside your monitor.
Back cover
Removing the back cover
Prerequisites
1. Follow the procedure in Before working inside your monitor.
2. Remove the stand.
3. Remove the VESA cover.
Steps
1. Remove the two screws (M4x10) that secure the back cover to the chassis assembly.
2. Remove the two screws (M4x4.5) that secure the back cover to the chassis assembly.
3. Using the plastic scribe, pry the back cover starting from the bottom edge of the monitor.
4. Lift and remove the back cover away from the monitor.
Figure 12. Removing the back cover
