16 | About your monitor
Bottom view
2 3 5 7 8 9
13
4
1 6 10
1414
Label Description Use
1 Security lock slot
(based on
Kensington Security
Slot
TM
)
Secures monitor with security cable lock (sold
separately).
2
Power connector
Connect the power cable.
3
HDMI 2.1
Connect your computer with the HDMI cable.
4
DisplayPort in
Connect your computer with the DisplayPort cable.
5
Thunderbolt
TM
4
downstream port
(15W) for daisy
chaining
(Video + Data)
Thunderbolt™ 4 downstream ports used only for daisy
chain to another monitor with Thunderbolt
TM
or USB-C
®
cable.
NOTE:
1) Thunderbolt™ 4 up to 40 Gbps bandwidth;
2) Supports up to two 5K monitors through the Daisy
chain;
3) The highest power output is up to 15 W or 5 V/3 A.
NOTE: Remove the rubber plug when using
Thunderbolt™ 4 downstream connector.
