18 | About your monitor
12
RJ45 port
Connect to Ethernet router with RJ45 cable. To enable
network access, either USB-C
®
or Thunderbolt
TM
4
upstream port must be connected to the host computer
with an appropriate cable mentioned above.
13 Stand lock Lock the stand to the monitor using a M3 x 8 mm screw
(screw not included).
14 Built-in speakers To output the sound from an audio input.
NOTE: Thunderbolt
TM
is a trademark of Intel Corporation.
Monitor specifications
Screen type Active matrix - TFT LCD
Panel Type In-plane switching Technology
Aspect ratio 21:9
Viewable image dimensions
Diagonal 1008.59 mm (39.7 in.)
Active Area
Horizontal 929.28 mm (36.59 in.)
Vertical 392.04 mm (15.43 in.)
Area 364314.9 mm
2
(564.69 in.
2
)
Pixel pitch 0.1815 mm x 0.1815 mm
Pixel per inch (PPI) 140
Viewing angle
Horizontal 178° (typical)
Vertical 178° (typical)
Brightness 450 cd/m² (typical)
600 cd/m² (HDR Peak)
Contrast ratio 2000 to 1 (typical)
Curvature 2500R
Display screen coating Anti-Glare with 3H hardness
Backlight LED Edgelight System
Response Time (Gray
to Gray)
5 ms (Fast mode)
8 ms (Normal mode)
