About your monitor | 31
Universal Serial Bus (USB)
This section gives you information about the USB ports available on your monitor.
NOTE: Up to 5 V/1.5 A typical (2 A max) on USB-A downstream port (port
with battery icon) with BC 1.2 compliance devices; up to 0.9 A on the
other five USB-A downstream ports; Up to 3 A on USB-C
®
downstream port
(port with icon) with 5 V/3 A compliance devices.
Your computer has the following USB ports:
• Two upstream - 1*TBT + 1*USB-C
®
at rear.
• Eight downstream - 2*USB-C
®
+ 1*USB-A at bottom, 1*TBT + 4*USB-A at rear.
Power Charging Port - the ports with battery icon supports fast current
charging capability if the device is BC 1.2 compatible. The USB Type-C
®
downstream port with icon supports fast current charging capability if the
device is 5 V/3 A compatible.
NOTE: The monitor’s USB ports work only when the monitor is on or in
Standby Mode. On in Standby Mode, if the USB cable (A to C or C to C) is
plugged in, the USB ports can work normally. Otherwise, follow the OSD
setting of Other USB Charging, if the setting is “On in Standby Mode”
then USB work normally, otherwise USB is disabled. If you turn off the
monitor and then turn it on, the attached peripherals may take a few
seconds to resume normal functionality.
SuperSpeed USB 10 Gbps (USB 3.2 Gen2) device
Transfer speed Data rate Maximum power consumption (each port)
SuperSpeed+ 10 Gbps 4.5 W
SuperSpeed 5 Gbps 4.5 W
High speed 480 Mbps 2.5 W
Full speed 12 Mbps 2.5 W
