Chapter 2 Installation and Wiring|VFD-S Series
2-20 Revision August 2008, SE09, SW V2.61
Two/Three wire control
M0
M1
M2
M3
M5
M4
E
GND
The wiring for
Pr.4-04=d1
Forward/Stop
Reverse/Stop
Reset
Multi-step 1
Common Signal
Multi-function
Input Terminals
Multi-step 2
Multi-step 3
M0
M1
M2
M3
M5
M4
E
GND
The wiring for
Pr.4-04=d2
Run/Stop
Forward/Reverse
Reset
Multi-step 1
Common Signal
Multi-function
Input Terminals
Multi-step 2
Multi-step 3
M0
M1
M2
M3
M5
M4
E
GND
The wiring for
Pr.4-04=d3
Stop
Run
REV/FWD
Multi-function
Input Terminals
Multi-step 1
Common Signal
Multi-step 3
Multi-step 2
