Delta Elektronika SM15K Series User Manual

REMOTE PROGRAMMING SM15K
25 / 32 DELTA ELEKTRONIKA B.V. rev. January 2021
LIMITS

Switch Voltage Limit ON or OFF and set value.

Switch Current Limits ON or OFF and set values.

Switch Power Limits ON or OFF and set values.
SOURCES

Set the program source for voltage control.

Set the program source for current control.

Set the program source for power control.
POWER SINK

Sink current when Remote ShutDown is activated.

Sink current when Interlock link is open.

Sink current when the Output is Off.
NETWORK

DHCP enabled / disabled.

IP Version.

Network IP address.

Network Subnet mask.

Network Gateway address.

Network interface MAC address.
INTERFACES (Slot1, 2, 3 and 4)
ISOLATED ANALOG

Voltage levels on analog programming and monitoring for
output voltage and current.

Level of Status signals ACF, DCF, LIMIT, RSD, OT, CC.
SERIAL & USB

Select BUS-type: USB, Differential, RS232.

Device channel nr.

Baudrate, Databits, Stopbits, Parity bits.

Slewrate, Termination, Simplex/Duplex.
DIGITAL I/O

Level of digital inputs A...H (High / Low).

Level of digital outputs A...H (High / Low).
ISOLATED CONTACTS

Status of the relay contact 1...4 (On / Off).

Level of the Interlock input (High / Low).

Level of the Enable input (High / Low).
MASTER / SLAVE

Enable or disable master / slave mode.

Select Master or Slave.

Number of units in parallel or series.
SEQUENCES

Upload sequences into the unit's volatile memory.

Synchronize memory to copy sequences from the volatile
to the non-volatile memory.

After switching off the unit, the sequences remain on the
power supply.

Monitor and make settings:
- View sequencer name
- View if it is loaded as active sequencer
- View if it has been build
- Mark for Non-Volatile
- Set start/stop conditions
- Set if to restore or retain output state and values after it
is terminated
- Mark for deletion

See paragraph 4 of this chapter for more information
about sequencer programming.
REGULATION
MISCELLANEOUS

Restore Regulation defaults – NEW.
VSENSE_CONTROL

Cable compensation by Proportional, Integral and
Derivative settings.

Set Upper_Limit and Lower_Limit.
V_CONTROL

Load compensation by Control Speed setting.
