AH Motion Controller – Operation Manual
9-10
_9
Error code Description
CPU
Status
LED indicator
status
ERROR
BUS
FAULT
16#1402
The actual arrangement of the I/O modules is not consistent with
the module table. (SM9)
Stop Keep ON
16#1403
An error occurs when the data is read from the module. (SM9)
Stop
Keep
ON
16#1405
The setting parameter of the module is not found. (SM9)
Stop
Keep
ON
16#140B
The number of network modules exceeds the limit. (SM9)
Stop
Keep
ON
16#140C
The checksum of the high-speed data exchange is incorrect.
Stop
Keep
ON
16#140D The ID of the actual power supply module is not the same as the ID
of the power supply module set in HWCONFIG. (SM9)
Stop Keep ON
16#140E The amount of data exchanged at a high speed exceeds the
maximum amount supported.
Stop Keep ON
16#140F
High-speed data exchange error
Stop
Keep
ON
16#1801
There is no interrupt service routine in the CPU module.
Continue
Keep
Keep
16#2000
There is no END in the program in the PLC. (SM5)
Stop
Blinking
Keep
16#2001
The program is incorrect. There is a syntax error.
Stop
Blinking
Keep
16#2002
GOEND is used incorrectly. (SM5)
Stop
Blinking
Keep
16#2003 The devices used in the program exceed the range. (SM0/SM5)
Self-define
d
Blinking Keep
16#2004
The part of the program specified by the label used in CJ/JMP is
incorrect, or the label is used repeatedly. (SM0/SM5)
Stop Blinking Keep
16#2005
The N value used in MC is not the same as the corresponding N
value used in MCR, or the number of N values used in MC is not the
same as the number of N values used in MCR. (SM5)
Stop Blinking Keep
16#2006
The N values used in MC do not start from 0, or the N values used
in MC are not continuous. (SM5)
Stop Blinking Keep
16#2007
The operands used in ZRST are not used properly. (SM5)
Stop
Blinking
Keep
16#200A
Invalid instruction (SM5)
Stop
Blinking
Keep
16#200B
The operand n or the other constant operands exceed the range.
(SM0/SM5)
Self-define
d
Blinking Keep
16#200C The operands overlap. (SM0/SM5)
Self-define
d
Blinking Keep
16#200D
An error occurs when the binary number is converted into the
binary-coded decimal number. (SM0/SM5)
Self-define
d
Blinking Keep
16#200E The string does not end with 0x00. (SM0/SM5)
Self-define
d
Blinking Keep
16#200F
The instruction does not support the modification by an index
register. (SM5)
Stop Blinking Keep
