Delta AH Series

Chapter 9 Troubleshooting
9-19
9_
Error code Description
CPU
Status
LED indicator
status
ERROR
BUS
FAULT
16#2116
External interrupt service routine 234 does not exist.
Stop
Blinking
Keep
16#2117
External interrupt service routine 235 does not exist.
Stop
Blinking
Keep
16#2118
External interrupt service routine 236 does not exist.
Stop
Blinking
Keep
16#2119
External interrupt service routine 237 does not exist.
Stop
Blinking
Keep
16#211A
External interrupt service routine 238 does not exist.
Stop
Blinking
Keep
16#211B
External interrupt service routine 239 does not exist.
Stop
Blinking
Keep
16#211C
External interrupt service routine 240 does not exist.
Stop
Blinking
Keep
16#211D
External interrupt service routine 241 does not exist.
Stop
Blinking
Keep
16#211E
External interrupt service routine 242 does not exist.
Stop
Blinking
Keep
16#211F
External interrupt service routine 243 does not exist.
Stop
Blinking
Keep
16#2120
External interrupt service routine 244 does not exist.
Stop
Blinking
Keep
16#2121
External interrupt service routine 245 does not exist.
Stop
Blinking
Keep
16#2122
External interrupt service routine 246 does not exist.
Stop
Blinking
Keep
16#2123
External interrupt service routine 247 does not exist.
Stop
Blinking
Keep
16#2124
External interrupt service routine 248 does not exist.
Stop
Blinking
Keep
16#2125
External interrupt service routine 249 does not exist.
Stop
Blinking
Keep
16#2126
External interrupt service routine 250 does not exist.
Stop
Blinking
Keep
16#2127
External interrupt service routine 251 does not exist.
Stop
Blinking
Keep
16#2128
An action in a sequential function chart is incorrectly assigned
qualifiers related to time.
Stop Blinking Keep
16#2129
The modifier R is assigned to an action in a sequential function
chart incorrectly.
Stop Blinking Keep
16#3040
Data in the E-CAM exceeds the range or does not exist.
Continue
Blinking
Keep
16#3100
Input parameters exceed the available setting range.
Continue
Blinking
Keep
16#3102
An error occurs in a sub-function block inside the function block.
Continue
Blinking
Keep
16#3103
The distance between the detecting sensors used for identifying
exeptional bags is a negative value.
Continue Blinking Keep
16#3104
Phasing is executed again before the previous phasing is
completed.
Continue Blinking Keep
16#3105
Superimposing is executed again before the previous
superimposing is completed.
Continue Blinking Keep
16#3106
Chain position compensation is triggered before the previous
compensation is completed.
Continue Blinking Keep
16#3107
Film axis position compensation is triggered before the previous
compensation is completed.
Continue Blinking Keep
