Amplon RT Series

z
Models: UPS802R2RT0B035 & UPS103R2RT0B035
MINI SLOT
MANUAL BYPASS SWITCH
EXTERNAL BATT. CONNECTOR 240V DC 46A
OUTPUT SOCKET-4
10A MAX. PER OUTLET
OUTPUT SOCKET-3
16A MAX. PER OUTLET
OUTPUT BREAKER-2
250V AC 25A
OUTPUT SOCKET-2
16A MAX. PER OUTLET
OUTPUT BREAKER-3
250V AC 25A
OUTPUT BREAKER-4
250V AC 20A
OUTPUT BREAKER-5
250V AC 20A
OUTPUT SOCKET-5
10A MAX. PER OUTLET
P2
P3
P4P1
RS-232
DRY CONTACT RS-485REPO
OUTPUT BREAKER-1
250V AC 20A
OUTPUT SOCKET-1
16A MAX.
WARNING:
OPENING THIS COVER PLATE WILL CAUSE
INVERTER SHUTDOWN.
ONLY AUTHORIZED SERVICE PERSONNEL
CAN OPEN AND OPERATE IT.
NORMA
L
UPS OUTPUT
L N
AC INPUT
N L
TMOV
1 2 3
4 5 6 77
89
12
13
14
16
15
11
10
)LJXUHN9$N9$5HDU3DQHO
No. Item Functions
1
MINI Slot
Connects to a Mini SNMP IPv6 / Mini Relay I/
O/ Mini MODBUS card. For more information,
please refer to
0,1,6ORW
.
2
Dry Contacts
1. Output dry contacts: Receive the UPS’s
event information to indicate the UPS
status or internal messages.
2. Input dry contacts: Let the UPS to receive
external control signals.
3. For more information, please refer to

'U\&RQWDFWV
.
3
REPO Port
When emergency events occur, it can shut
down the UPS safely and immediately. Please
refer to
5(323RUW
for details.
4
RS-485 Port
Connects to a computer so you can monitor
the UPS status.
