Delta ASD-A2R-1B43 Series User Manual

Chapter 8 ParametersASDA-A2R Series
Revision December, 2014
8-3
Monitor and General Output Parameter
Parameter Abbr. Function Default Unit
Control Mode
Related
Section
PT PR S T
P0-30 MAP6 Mapping Parameter # 6
No need
to
initialize
N/A O O O O 4.3.5
P0-31 MAP7 Mapping Parameter # 7
No need
to
initialize
N/A O O O O 4.3.5
P0-32 MAP8 Mapping Parameter # 8
No need
to
initialize
N/A O O O O 4.3.5
P0-35 MAP1A
Target Setting of Mapping
Parameter P0-25
0x0 N/A O O O O 4.3.5
P0-36 MAP2A
Target Setting of Mapping
Parameter P0-26
0x0 N/A O O O O 4.3.5
P0-37 MAP3A
Target Setting of Mapping
Parameter P0-27
0x0 N/A O O O O 4.3.5
P0-38 MAP4A
Target Setting of Mapping
Parameter P0-28
0x0 N/A O O O O 4.3.5
P0-39 MAP5A
Target Setting of Mapping
Parameter P0-29
0x0 N/A O O O O 4.3.5
P0-40 MAP6A
Target Setting of Mapping
Parameter P0-30
0x0 N/A O O O O 4.3.5
P0-41 MAP7A
Target Setting of Mapping
Parameter P0-31
0x0 N/A O O O O 4.3.5
P0-42 MAP8A
Target Setting of Mapping
Parameter P0-32
0x0 N/A O O O O 4.3.5
P0-46★
SVSTS
Servo Digital Output Status
Display
0 N/A O O O O -
P1-04 MON1
MON1
A
nalog Monitor Output
Proportion
100
%(full
scale)
O O O O 6.4.4
P1-05 MON2
MON2
A
nalog Monitor Output
Proportion
100
%(full
scale)
O O O O 6.4.4
Filter and Resonance Suppression Parameter
Parameter Abbr. Function Default Unit
Control Mode
Related
Section
PT PR S T
P1-06 SFLT
Analog Speed Command
(Low-pass Filter)
0 ms O 6.3.3
P1-07 TFLT
Analog Torque (force)
Command (Low-pass Filter)
0 ms O 6.4.3
P1-08 PFLT
Smooth Constant of Position
Command
(Low-pass Filter)
0
10
ms
O O 6.2.6
