Chapter 8 ParametersASDA-A2R Series
8-120 Revision December, 2014
Settings：
The setting of transmission speed is divided into Z, Y, X
(hexadecimal):
0 Z Y X
Communication
Port
－
CAN
－
RS-232/485
Range 0 0~4 0 0~5
 Definition of X setting value
0: 4800
1: 9600
2: 19200
3: 38400
4: 57600
5: 115200
 Definition of Z setting value
0: 125 Kbit/s
1: 250 Kbit/s
2: 500 Kbit/s
3: 750 Kbit/s
4: 1.0 Mbit/s
NOTE
1）If this parameter is set via CAN, only Z can be set and the
others remain.
2）The communication speed of USB is 1.0 Mbit/s only and is
unchangeable.
P3-02 PTL Communication Protocol
Address: 0304H
0305H
Operational
Interface：
Panel / Software Communication
Related Section:
9.2
Default：
6
Control
Mode：
ALL
Unit：
-
Range：
0 ~ 0x8
Data Size：
16bit
Format：
HEX
Settings：
The definition of the setting value is as the followings:
0: 7, N, 2 (MODBUS, ASCII)
1: 7, E, 1 (MODBUS, ASCII)
2: 7, O,1 (MODBUS, ASCII)
3: 8, N, 2 (MODBUS, ASCII)
4: 8, E, 1 (MODBUS, ASCII)
