Delta ASD-A2R-1B43 Series User Manual

Chapter 8 ParametersASDA-A2R Series
8-268 Revision December, 2014
PM-19 Overload Gain (Temperature Rises)
Address:
Applicable
motor type：
ALL
Related Section: -
Operational
Interface：
Panel / Software Communication
Default：
100
Unit：
%
Range：
15~600
Data Size：
16bit
Format：
DEC
Settings：
Load Proportion Operation Time
0% -12sec × PM-20
20% -12.3sec ×PM-20
40% -13.6sec ×PM-20
60% -16.3sec ×PM-20
80% -22.6sec ×PM-20
100% N/A
120% 26.38sec ×PM-19
140% 35.2sec ×PM-19
160% 17.6sec ×PM-19
180% 11.2sec ×PM-19
200% 8sec ×PM-19
220% 6.1sec ×PM-19
240% 4.8sec ×PM-19
260% 3.9sec ×PM-19
280% 3.3sec ×PM-19
300% 2.8sec ×PM-19
320% 2.5sec ×PM-19
340% 2.2sec ×PM-19
360% 2.0sec ×PM-19
380% 1.8sec ×PM-19
400% 1.6sec ×PM-19
420% 1.4sec ×PM-19
440% 1.3sec ×PM-19
460% 1.2sec ×PM-19
480% 1.1sec ×PM-19
500% 1.0sec ×PM-19
Operation time indicates the time that protection level turns to
overload level from the normal one. When it turns to overload
level, the function of overload protection will be triggered.
Following is the example with 200% of current:
