Chapter 7 Optional AccessoriesCFP2000
7-15
Input AC reactor
Delta part #
Dimensions
DR060AP405 Refer to the diagram above
Installing screw M6
PE M6
Tightening torque: 3±1.5 N
Unit: mm
Table 7-11
Figure 7-17
