Chapter 9 Specifications CFP2000
9-2
9-1 460V Models
Frame Size A B
Model VFD_ _ _ FP4EA- _ _ _ 007 015 022 037 040 055 075 110 150 185 220
Out
p
ut Ratin
g
Li
g
ht dut
y
Rated output capacity [kVA] 2.4 3.3 4.4 6.8 8.4 10.4 14.3 19 25 30 36
Rated output current [A] 3.0 4.2 5.5 8.5 10.5 13 18 24 32 38 45
Applicable motor output [kW] 0.75 1.5 2.2 3.7 4 5.5 7.5 11 15 18.5 22
Applicable motor output [HP] 1 2 3 5 5 7.5 10 15 20 25 30
Overload tolerance 120% of rated current can endure for 1 minute during every 5 minutes
Max. output frequency [Hz] 599 Hz
Carrier frequency [kHz] 2–15 (6 kHz)
2–10
(6kHz)
Normal dut
y
Rated output capacity [kVA] 1.4 2.4 3.2 4.8 7.2 8.4 9.6 14.3 19 25 30
Rated output current [A] 1.7 3.0 4.0 6.0 9.0 10.5 12 18 24 32 38
Applicable motor output [kW] 0.4 0.75 1.5 2.2 3.7 4 5.5 7.5 11 15 18.5
Applicable motor output [HP] 0.5 1 2 3 5 5 7.5 10 15 20 25
Overload tolerance
120% of rated current can endure for 1 minute during every 5 minutes
160% of rated current can endure for 3 seconds during every 30 seconds.
Max. output frequency [Hz] 599 Hz
Carrier frequency [kHz] 2–15 (6 kHz)
2–10
(6kHz)
In
p
ut Ratin
g
Input current [A] Light duty 3.0 4.2 5.5 8.5 10.5 13 18 24 32 38 45
Input current [A] Normal duty 1.7 3 4 6 9.0 10.5 12 18 24 32 38
Rated voltage / Frequency 3-phase 380–480 V
AC
[ -15%–10%], 50/60 Hz
Operating voltage range 323–528 V
AC
Frequency tolerance 47–63 Hz
Efficiency [%] 97
Power factor >0.98
Weight [kg] 6.8 14.5
Cooling method Natural cooling Fan cooling
Braking chopper Frame A to C: built-in
DC choke Built-in DC reactor EN61000-3-12
EMC Filter Built-in EMC Filter EN61800-3 C1 & C2
NOTE
 The carrier frequency is default. Increasing the carrier frequency requires a reduction in current. Please refer to Section 9-4
Derating Curve for Ambient Temperature.
 Select the AC motor drive with capacity one grade oarger for the impact load application.
