Delta CFP2000 Series - Page 168

Chapter 9 Specifications CFP2000
9-3
460V Models
Frame Size C D0 D
Model VFD_ _ _ FP4EA- _ _ _ 300 370 450 550 750 900
Out
p
ut Ratin
g
Li
g
ht dut
y
Rated output capacity [kVA] 48 58 73 88 120 143
Rated output current [A] 60 73 91 110 150 180
Applicable motor output [kW] 30 37 45 55 75 90
Applicable motor output [HP] 40 50 60 75 100 125
Overload tolerance 120% of rated current can endure for 1 minute during every 5 minutes
Max. output frequency [Hz] 599 Hz
Carrier frequency [kHz] 2–10 (6 kHz)
2–9
(4 kHz)
Normal dut
y
Rated output capacity [kVA] 36 48 58 73 88 120
Rated output current [A] 45 60 73 91 110 150
Applicable motor output [kW] 22 30 37 45 55 75
Applicable motor output [HP] 30 40 50 60 75 100
Overload tolerance
120% of rated current can endure for 1 minute during every 5 minutes
160% of rated current can endure for 3 seconds during every 30 seconds.
Max. output frequency [Hz] 599 Hz
Carrier frequency [kHz] 2–10 (6 kHz)
2–9
(4 kHz)
In
p
ut Ratin
g
Input current [A] Light duty 60 73 91 110 150 180
Input current [A] Normal duty 45 60 73 91 110 150
Rated voltage / Frequency 3-phase 380–480 V
AC
(-15%–10%), 50/60 Hz
Operating voltage range 323–528 V
AC
Frequency tolerance 47–63 Hz
Efficiency [%] 97
Power factor >0.98
Weight [kg] 26.5 42 59.5
Cooling method Fan cooling
Braking chopper Frame A to C (built-in)
DC choke Built-in DC reactor EN61000-3-12
EMC Filter Built-in EMC Filter EN61800-3 C1 & C2
NOTE
 The carrier frequency is default. Increasing the carrier frequency requires a reduction in current. Please refer to Section 9-4
Derating Curve for Ambient Temperature.
 Select the AC motor drive with capacity one grade oarger for the impact load application.
