Delta CP2000 Series User Manual

Chapter 7 Optional AccessoriesCP2000
7-3
Table 7-2
Table 7-3
Applicable
Motor
125%Braking Torque 10%ED *
1
Max. Brake Torque *
2
HP kW
Braking
Torque
[kg-m]
Brake
Unit
Braking Resistor series for each
Brake Unit *
4
Resistor value
spec. for each
AC motor Drive
Total
Braking
Current [A]
Min.
Resistor
Value [Ω]
Max. Total
Braking
Current [A]
Peak
Power
[kW]
VFDB *
3
P/N Q’ty Usage
250 185
108.3 4160*1
BR1K5W012 12
6 parallel,
2 series
18000W 4Ω 190 4.0 190 144.4
300
220 125.2 4185*1
BR1K5W012 14
7 parallel,
2 series
21000W 3.4Ω 225 3.4 225
172.0
375
280 148.9 4110*2
BR1K2W015 10
5 parallel,
2 series
24000W 3Ω 252 3.0 252
191.5
425
315 189.6 4160*2
BR1K5W012 12
6 parallel,
2 series
36000W 2Ω 380 2.0 380 288.8
475
355 213.3 4160*2
BR1K5W012 12
6 parallel,
2 series
36000W 2Ω 380 2.0 380 288.8
536
400 240.3 4185*2
BR1K5W012 14
7 parallel,
2 series
42000W 1.7Ω 450 1.7 450 344.2
675
500 304.7 4185*3
BR1K5W012 12
6 parallel,
2 series
54000W 1.3Ω 600 1.1 675 513.0
745
560 379.1 4185*3
BR1K5W012 14
7 parallel,
2 series
63000W 1.1Ω 675 1.1 675 513.0
850
630 426.5 4160*4
BR1K5W012 12
6 parallel,
2 series
72000W 1.0Ω 760 1.0 760 577.6
575V Model
Applicable
Motor [kW]
125%Braking Torque 10%ED *
1
Max. Brake Torque *
2
ND LD
Braking
Torque
[kg-m]
Brake
Unit
Braking Resistor series for each
Brake Unit *
4
Resistor value
spec. for each
AC motor Drive
Total
Braking
Current [A]
Min.
Resistor
Value [Ω]
Max. Total
Braking
Current [A]
Peak
Power
[kW]
VFDB *
3
P/N Q’ty Usage
0.75 1.5 0.5
-
BR080W750 1 - 80W 750Ω 1.2 280.0 4 4.5
1.5 2.2 1
-
BR200W360 1 - 200W 360Ω 2.6 186.7 6 6.7
2.2 3.7 1.5
-
BR300W400 1 - 300W 400Ω 2.3 160.0 7 7.8
3.7 5.5 2.5
-
BR500W100 1 - 500W 100Ω 9.2 93.3 12 13.4
5.5 7.5 3.7
-
BR750W140 1 - 750W 140Ω 6.6 80.0 14 15.7
7.5 11 5.1
-
BR1K0W075 1 - 1000W 75Ω 12.3 70.0 16 17.9
11 15 7.4
-
BR1K1W091 1 - 1100W 91Ω 10.1 62.2 18 20.2
690V Model
Applicable
Motor [kW]
*
1
125%Braking Torque 10%ED *
2
Max. Brake Torque
LD ND
Braking
Torque
[kg-m]
Brake
Unit
*
3
Braking Resistor series for each
Brake Unit
Resistor value
spec. for each
AC motor Drive
Total
Braking
Current [A]
Min.
Resistor
Value [Ω]
Max. Total
Braking
Current [A]
Peak
Power
[kW]
*
4
VFDB P/N Q’ty Usage
18.5 15 10.2
- BR1K0W039 2 2 series
2000W 78Ω 14.4 58.9 19 21.3
22 18.5 12.5
- BR1K2W033 2 2 series
2400W 66Ω 17.0 58.9 19 21.3
30 22 14.9
- BR1K5W027 2 2 series
3000W 54Ω 20.7 43.1 26 29.1
37 30 20.3
- BR1K2W015 3 3 series
3600W 45Ω 24.9 43.1 26 29.1
45 37 25 6055*1
BR1K2W033 4
2 parallel,
2 series
4800W 33Ω 33.9 24.3 46 51.5
55 45 30.5 6055*1
BR1K5W027 4
2 parallel,
2 series
6000W 27Ω 41.5 24.3 46 51.5
75 55 37.2 6110*1
BR1K2W033 6
3 parallel,
2 series
7200W 22Ω 50.9 12.2 92 103.0
90 75 50.8 6110*1
BR1K5W027 6
3 parallel,
2 series
9000W 18Ω 62.2 12.2 92 103.0
110 90 60.9 6110*1
BR1K5W027 8
4 parallel,
2 series
12000W 13.5Ω 83.0 12.2 92 103.0
132 110 74.5 6160*1
BR1K2W015 12
4 parallel,
3 series
14400W 11.3Ω 99.6 8.2 136 152.3

Delta CP2000 Series Specifications

General

Output Voltage	0 ~ Input Voltage
Communication Interface	RS-485
Storage Temperature	-20°C to 60°C
Input Voltage	200-240V AC, 380-480V AC
Protection Functions	Overcurrent, Overvoltage, Undervoltage, Overtemperature, Short Circuit
