Delta CP2000 Series User Manual

Chapter 7 Optional AccessoriesCP2000
7-4
Table 7-4
Applicable
Motor [kW]
*
1
125%Braking Torque 10%ED *
2
Max. Brake Torque
LD ND
Braking
Torque
[kg-m]
Brake
Unit
*
3
Braking Resistor series for each
Brake Unit
Resistor value
spec. for each
AC motor Drive
Total
Braking
Current [A]
Min.
Resistor
Value [Ω]
Max. Total
Braking
Current [A]
Peak
Power
[kW]
*
4
VFDB P/N Q’ty Usage
160 132 89.4 6160*1
BR1K5W027 10
5 parallel,
2 series
15000W 10.8Ω 103.7 8.2 136 152.3
200 160 108.3 6200*1
BR1K5W027 12
6 parallel,
2 series
18000W 9.0Ω 124.4 6.9 162 181.4
250 200 135.4 6110*2
BR1K5W027 8
4 parallel,
2 series
24000W 6.8Ω 165.9 6.1 184 206.1
315 250 169.3 6160*2
BR1K5W027 10
5 parallel,
2 series
30000W 5.4Ω 207.4 4.1 272 304.6
400 315 213.3 6200*2
BR1K5W027 12
6 parallel,
2 series
36000W 4.5Ω 248.9 3.5 324 362.9
450 355 240.3 6200*2
BR1K5W027 14
7 parallel,
2 series
42000W 3.9Ω 290.4 3.5 324 362.9
560 450 304.7 6200*3
BR1K5W027 12
6 parallel,
2 series
54000W 3.0Ω 373.3 2.3 486 544.3
630 630 426.5 6200*4
BR1K5W027 12
6 parallel,
2 series
72000W 2.3Ω 497.8 1.7 648 725.8
*
1
Calculation for 125% brake toque: (kW)*125%*0.8; where 0.8 is motor efficiency.
Because of the limited resistor power, the longest operation time for 10%ED is 10 seconds (on: 10 sec. / off: 90 sec.).
*
2
Refer to Chapter 7 “Brake Module and Brake Resistors” in application manual for “Operation Duration & ED” vs. “Braking
Current”.
*
3
For heat dissipation, a resistor of 400 W or lower should be fixed to the frame and maintain the surface temperature below
250°C; a resistor of 1000W and above should maintain the surface temperature below 350°C.
*
4
Please refer to VFDB series Braking Module Instruction for more detail on braking resistor.
NOTE
1. Specification and Appearance of Brake Resistors
1-1 Wire wound resistors:
For 1000 W and above. Refer to the following appearance of wire wound resistor
(Figure 7-1) and its model and specification comparison table (Table 7-5) for det
ails.
A
B
C D
H
F
K
G
E
L
Models and Specifications Comparison Table of Wire Wound Resistors:
Table 7-5
Unit: mm
Fi
g
ure 7-1
