Delta CP2000 Series User Manual

Chapter 7 Optional AccessoriesCP2000
7-39
Model
kW HP
Rated Amps
of AC Reactor
(Arms)
Max. continuous
Amps (Arms)
3% impedance
(mH)
5% impedance
(mH)
Built-in
DC
reactor
3% Input AC reactor
Delta part #
Normal
Duty
Light
Duty
Normal
Duty
Light
Duty
Normal
Duty
Light
Duty
Normal
Duty
Light
Duty
Normal
Duty
Light
Duty
1320 132 175 220 260 352 312 0.110 0.098 0.183 0.163 Yes DR220LP110 DR260LP098
1600 160 215 260 310 416 372 0.098 0.078 0.163 0.13 Yes DR260LP098 DR310LP078
1850 185 250 310 370 496 444 0.078 0.066 0.13 0.11 Yes DR310LP078 DR370LP066
2200 220 300 370 460 592 552 0.066 0.054 0.11 0.09 Yes DR370LP066 DR460LP054
2800 280 375 460 530 736 636 0.054 0.044 0.09 0.073 Yes DR460LP054 DR550LP044
3150 315 420 550 616 880 739.2 0.044 0.039 0.073 0.065 Yes DR550LP044 DR616LP039
3550 355 475 616 683 985.6 819.6 0.039 0.036 0.065 0.06 Yes DR616LP039 DR683LP036
4500 450 600 683 770 1092.8 924 0.036 0.028 0.06 0.047 Yes DR683LP036 DR866LP028
5000 500 675 866 912 1385.6 1094.4 0.028 0.028 0.047 0.047 Yes DR866LP028 DR866LP028*
2
5600 560 650 930 1094 1488 1318.2 0.026 0.022 0.043 0.037 Yes
Contact Delta for more
information
6300 630 760 1094 1212 1750.4 1454.4 0.022 0.020 0.037 0.033 Yes
*Note 1: Use with DR003A0810, but the inductance value will be 3% short.
*Note 2: Use with DR866AP028, the value is 5.3% greater than the rated current, which may cause slightly over-heat.
575V, 50 / 60 Hz, 3-phase
Model
kW HP
Rated Amps of
AC Reactor (Arms)
Max.
continuous
Amps
(Arms)
3% impedance (mH) 5% impedance (mH)
Normal
Duty
Light
Duty
Normal
Duty
Light
Duty
Normal
Duty
Light
Duty
015 1.5 2 2.5 3 4.2 10.567 8.806 17.612 14.677
022 2.2 3 3.6 4.3 5.9 7.338 6.144 12.230 10.239
037 3.7 5 5.5 6.7 9.1 4.803 3.943 8.005 6.572
055 5.5 7.5 8.2 9.9 13.7 3.222 2.668 5.369 4.447
075 7.5 10 10 12.1 16.5 2.642 2.183 4.403 3.639
110 11 15 15.5 18.7 25.7 1.704 1.413 2.841 2.355
150 15 20 20 24.2 33.3 1.321 1.092 2.201 1.819
690V, 50 / 60 Hz, 3-phase
Model
kW HP
Rated Amps of
AC Reactor (Arms)
Max. continuous
Amps (Arms)
3% impedance (mH) 5% impedance (mH)
Normal Duty Light Duty Normal Duty Light Duty Normal Duty Light Duty Normal Duty Light Duty
185 18.5 25 20 24 30.0 28.8 1.902 1.585 3.170 2.642
220 22 30 24 30 36.0 36.0 1.585 1.268 2.642 2.113
300 30 40 30 36 45.0 43.2 1.268 1.057 2.113 1.761
370 37 50 36 45 54.0 54.0 1.057 0.845 1.761 1.409
450 45 60 45 54 67.5 64.8 0.845 0.704 1.409 1.174
550 55 75 54 67 81.0 80.4 0.704 0.568 1.174 0.946
750 75 100 67 86 100.5 103.2 0.568 0.442 0.946 0.737
900 90 125 86 104 129.0 124.8 0.442 0.366 0.737 0.610
1100 110 150 104 125 156.0 150.0 0.366 0.304 0.610 0.507
1320 132 175 125 150 187.5 180.0 0.304 0.254 0.507 0.423
1600 160 215 150 180 225.0 216.0 0.254 0.211 0.423 0.352
2000 200 270 180 220 270.0 264.0 0.211 0.173 0.352 0.288
2500 250 335 220 290 330.0 348.0 0.173 0.131 0.288 0.219
Table 7-47
Table 7-48
