Specifications of AC output reactors (standard item)
Following tables show the standard AC output reactors specification of Delta CP2000:
200V–230V, 50 / 60 Hz
Model
kW HP
Rated Amps
of AC Reactor
(Arms)
Max. continuous
Amps (Arms)
3% Impedance
(mH)
5% Impedance
(mH)
Built-in
DC
reactor
3% Input AC reactor
Delta part #
Normal
Duty
Light
Duty
Normal
Duty
Light
Duty
Normal
Duty
Light
Duty
Normal
Duty
Light
Duty
Normal
Duty
Light
Duty
007 0.75 1 4.6 5 7.36 6 2.536 2.536 4.227 4.227 No
DR005L0254 DR005L0254
015 1.5 2 5 7.5 8 9 2.536 1.585 4.227 2.642 No
DR005L0254 DR008L0159
022 2.2 3 8 10 12.8 12 1.585 1.152 2.642 1.92 No
DR008L0159 DR011L0115
037 3.7 5 11 15 17.6 18 1.152 0.746 1.92 1.243 No
DR011L0115 DR017LP746
055 5.5 7.5 17 21 27.2 25.2 0.746 0.507 1.243 0.845 No
DR017LP746 DR025LP507
075 7.5 10 25 31 40 37.2 0.507 0.38 0.845 0.633 No
DR025LP507 DR033LP320
110 11 15 33 46 52.8 55.2 0.38 0.26 0.633 0.433 No
DR033LP320 DR049LP215
150 15 20 49 61 78.4 73.2 0.26 0.196 0.433 0.327 No
DR049LP215 DR065LP162
185 18.5 25 65 75 104 90 0.196 0.169 0.327 0.282 No
DR065LP162 DR075LP170
220 22 30 75 90 120 108 0.169 0.141 0.282 0.235 No
DR075LP170 DR090LP141
300 30 40 90 105 144 126 0.141 0.12 0.235 0.2 No
DR090LP141 DR105LP106
370 37 50 120 146 192 175.2 0.12 0.087 0.2 0.145 Yes
DR105LP106 DR146LP087
450 45 60 146 180 233.6 216 0.087 0.07 0.145 0.117 Yes
DR146LP087 DR180LP070
550 55 75 180 215 288 258 0.07 0.059 0.117 0.098 Yes
DR180LP070 DR215LP059
750 75 100 215 276 344 331.2 0.059 0.049 0.098 0.082 Yes
DR215LP059 DR276LP049
900 90 125 255 322 408 386.4 0.049 0.037 0.082 0.062 Yes
DR276LP049 DR346LP037
380V–460V, 50 / 60 Hz
Model
kW HP
Rated Amps
of AC Reactor
(Arms)
Max. continuous
Amps (Arms)
3% impedance
(mH)
5% impedance
(mH)
Built-in
DC
reactor
3% Input AC reactor
Delta part #
Normal
Duty
Light
Duty
Normal
Duty
Light
Duty
Normal
Duty
Light
Duty
Normal
Duty
Light
Duty
Normal
Duty
Light
Duty
007 0.75 1 2.8 3 4.48 3.6 9.058 8.102 15.097 13.503 No DR003L0810*
1
DR003L0810
015 1.5 2 3 4.2 4.8 5.04 8.102 6.077 13.503 10.128 No DR003L0810 DR004L0607
022 2.2 3 4 5.5 6.4 6.6 6.077 4.050 10.128 6.75 No DR004L0607 DR006L0405
037 3.7 5 6 8.5 9.6 10.2 4.050 2.700 6.75 4.5 No DR006L0405 DR009L0270
040 4 5 9 10.5 14.4 12.6 2.700 2.315 4.5 3.858 No DR009L0270 DR010L0231
055 5.5 7.5 10.5 13 16.8 15.6 2.315 2.025 3.858 3.375 No DR010L0231 DR012L0202
075 7.5 10 12 18 19.2 21.6 2.025 1.35 3.375 2.25 No DR012L0202 DR018L0117
110 11 15 18 24 28.8 28.8 1.35 1.01 2.25 1.683 No DR018L0117 DR024LP881
150 15 20 24 32 38.4 38.4 1.01 0.76 1.683 1.267 No DR024LP881 DR032LP660
185 18.5 25 32 38 51.2 45.6 0.76 0.639 1.267 1.065 No DR032LP660 DR038LP639
220 22 30 38 45 60.8 54 0.639 0.541 1.065 0.902 No DR038LP639 DR045LP541
300 30 40 45 60 72 72 0.541 0.405 0.902 0.675 No DR045LP541 DR060LP405
370 37 50 60 73 96 87.6 0.405 0.334 0.675 0.557 No DR060LP405 DR073LP334
450 45 60 73 91 116.8 109.2 0.334 0.267 0.557 0.445 Yes DR073LP334 DR091LP267
550 55 75 91 110 145.6 132 0.267 0.221 0.445 0.368 Yes DR091LP267 DR110LP221
750 75 100 110 150 176 180 0.221 0.162 0.368 0.27 Yes DR110LP221 DR150LP162
900 90 125 150 180 240 216 0.162 0.135 0.27 0.225 Yes DR150LP162 DR180LP135
1100 110 150 180 220 288 264 0.135 0.110 0.225 0.183 Yes DR180LP135 DR220LP110
Table 7-46

Delta CP2000 Series Specifications

General

Output Voltage	0 ~ Input Voltage
Communication Interface	RS-485
Storage Temperature	-20°C to 60°C
Input Voltage	200-240V AC, 380-480V AC
Protection Functions	Overcurrent, Overvoltage, Undervoltage, Overtemperature, Short Circuit
