Delta CP2000 Series User Manual

Chapter 8 Option CardsCP2000
8-20
Parameter Function Set value (Dec) Explanation
Pr.09-80 Netmask -1 255 Netmask 255.255.255.0
Pr.09-81 Netmask -2 255 Netmask 255.255.255.0
Pr.09-82 Netmask -3 255 Netmask 255.255.255.0
Pr.09-83 Netmask -4 0 Netmask 255.255.255.0
Pr.09-84 Default gateway -1 192 Default gateway 192.168.1.1
Pr.09-85 Default gateway -2 168 Default gateway 192.168.1.1
Pr.09-86 Default gateway -3 1 Default gateway 192.168.1.1
Pr.09-87 Default gateway -4 1 Default gateway 192.168.1.1
8-9-6 LED Indicator & Troubleshooting
There are 2 LED indicators on CMC-EIP01: POWER LED and LINK LED. The POWER LED
displays the status of power supply, and the LINK LED displays the connection status of the
communication.
LED Indicators
LED Status Indication How to correct it?
POWER Green
ON Power supply in normal status --
OFF No power supply
Check the power supply.
LINK Green
ON
Network connection in normal
status
--
Flashes Network in operation
--
OFF Network not connected
Check if the network cable is
connected.
Troubleshooting
Abnormality Cause How to correct it?
POWER LED OFF
AC motor drive not powered
Check if AC motor drive is powered, and if the
power supply is normal.
CMC-EIP01 not connected to
AC motor drive
Make sure CMC-EIP01 is connected to AC motor
drive.
LINK LED OFF
CMC-EIP01 not connected to
network
Make sure the network cable is correctly connected
to network.
Poor contact to RJ45
connector
Make sure RJ45 connector is connected to
Ethernet port.
No communication
card found
CMC-EIP01 not connected to
network
Make sure CMC-EIP01 is connected to network.
PC and CMC-EIP01 in
different networks and blocked
by network firewall.
Search by IP or set up relevant settings by AC
motor drive keypad.
Fail to open
CMC-EIP01 setup
page
CMC-EIP01 not connected to
network
Make sure CMC-EIP01 is connected to the
network.
Incorrect communication
setting in DCISoft
Make sure the communication setting in DCISoft is
set to Ethernet.
PC and CMC-EIP01 in
different networks and blocked
by network firewall.
Conduct the setup by AC motor drive keypad.

Delta CP2000 Series Specifications

General

Output Voltage	0 ~ Input Voltage
Communication Interface	RS-485
Storage Temperature	-20°C to 60°C
Input Voltage	200-240V AC, 380-480V AC
Protection Functions	Overcurrent, Overvoltage, Undervoltage, Overtemperature, Short Circuit
