Delta CP2000 Series User Manual

Chapter 09 SpecificationsCP2000
9-4
460V Series
Frame D E F G H
Model VFD_ _ _ _CP43_-_ _ 750 900 1100 1320 1600 1850 2200 2800 3150 3550 4000 5000 5600 6300
*
1
Output rating
Light duty
Rated output capacity
[kVA]
120 143 175 207 247 295 367 422 491 544 613 741 872 966
Rated output current
[A]
150*
2
180 220 260*
2
310 370*
2
460 530 616 683 770 930 1094 1212
Applicable motor
output [kW]
75 90 110 132 160 185 220 280 315 355 400 500 560 630
Applicable motor
output [HP]
100 120 150 175 215 250 300 375 425 475 536 675 745 850
Overload capacity 120% of rated output current: 1 minute for every 5 minutes
Max. output frequency
[Hz]
599 400
Carrier Frequency
[kHz]
2–10
(Default: 6)
2–9
(Default: 4)
Normal duty
Rated output capacity
[kVA]
88 120 143 175 207 247 295 367 438 491 544 690 741 872
Rated output current
[A]
110 150 180 220 260 310 370 460 550 616 683 866 930 1094
Applicable motor
output [kW]
55 75 90 110 132 160 185 220 280 315 355 450 500 560
Applicable motor
output [HP]
75 100 125 150 175 215 250 300 375 425 475 600 675 850
Overload capacity
120% of rated output current: 1 minute for every 5 minutes;
160% of rated output current: 3 seconds for every 25 seconds
Max. output frequency
[Hz]
599 400
Carrier frequency
[kHz]
2–10
(Default: 6)
2–9
(Default: 4)
Input rating
Input current
[A]
Light duty 150 180 220 260 310 370 460 530 616 683 770 930 1094 1212
Normal duty 114 157 167 207 240 300 380 400 494 555 625 866 930 1094
Rated voltage / frequency 3-phase 380–480 V
AC
[-15%– +10%], 50/60 Hz
Operating voltage range 323–528 V
AC
Frequency tolerance 47–63 Hz
Efficiency [%] 97.8 98.2
Power factor >0.98
Drive weight [Kg] 38.5± 1.5 64.8± 1.5 86.5± 1.5 134± 4 228
Cooling method Fan cooling
Braking chopper Frame D–H: Optional
DC choke Frame D–H: Built-in 3%
EMC filter Frame D–H: Optional
NOTE
 The carrier frequency is default. Increasing the carrier frequency requires a reduction in current. Please refer to Chapter
9-7 Derating Curve of Ambient Temperature.
 Select the AC motor drive with capacity one grade larger for the impact load application.
 Refer to Chapter 9-6 Specification for Operation Temperature and Protection Level for the protection level of each model.
 *
1
The default setting is Light Duty, you can select Normal Duty and Light Duty by setting Pr.00-16.
 *
2
It means the rated output current is for the models of Version B. (e.g. VFD015CP43B-21)
 Model VFD5000CP43A-xx does not have UL certification.

Delta CP2000 Series Specifications

General

Output Voltage	0 ~ Input Voltage
Communication Interface	RS-485
Storage Temperature	-20°C to 60°C
Input Voltage	200-240V AC, 380-480V AC
Protection Functions	Overcurrent, Overvoltage, Undervoltage, Overtemperature, Short Circuit
