Chapter 11 Summary of Parameter SettingsCP2000
11-28
Pr. Parameter Name Setting Range Default
06-61 Software detection GFF filter time 0.00–655.35 sec. 0.10
06-63
Operation time of fault record 1
(Day)
0–65535 days
Read
only
06-64
Operation time of fault record 1
(Minutes)
0–1439 min.
Read
only
06-65
Operation time of fault record 2
(Day)
0–65535 days
Read
only
06-66
Operation time of fault record 2
(Minutes)
0–1439 min.
Read
only
06-67
Operation time of fault record 3
(Day)
0–65535 days
Read
only
06-68
Operation time of fault record 3
(Minutes)
0–1439 min.
Read
only
06-69
Operation time of fault record 4
(Day)
0–65535 days
Read
only
06-70
Operation time of fault record 4
(Minutes)
0–1439 min.
Read
only
06-71 Low current setting level
0.0–100.0% (100% corresponds to the light-load rated
current of the drive)
0.0
06-72 Low current detection time 0.00–360.00 sec. 0.00
06-73 Low current action
0: No function
1: Fault and coast to stop
2: Fault and ramp to stop by the 2
nd
deceleration time
3: Warn and continue operation
0
06-76 dEb motion offset
230V: 0.0–200.0 V
DC
460V: 0.0–200.0 V
DC
575V: 0.0–200.0 V
DC
690V: 0.0–200.0 V
DC
20.0
40.0
50.0
60.0
06-80 Fire mode
0: Disable
1: Operates in counter clockwise direction
2: Operates in clockwise direction
0
06-81
Operating frequency when
running fire mode
0.00–599.00 Hz 60.00
06-82 Enable bypass on fire mode
0: Disable bypass
1: Enable bypass
0
06-83 Bypass delay time on fire mode 0.0–6550.0 sec. 0.0
06-84
Number of times of reset in fire
mode
0–10 0
06-85
Length of time of reset in fire
mode
0.0–6000.0 sec. 60.0
06-86 Fire mode motion
bit0: 0=Open Loop; 1=Close Loop (PID control)
bit1: 0=Manual reset fire mode; 1=Auto reset fire mode
0: Open loop control and manual reset fire mode
1: Close loop control and manual reset fire mode
2: Open loop control and auto reset fire mode
3: Close loop control and auto reset fire mode
0
06-87 Fire mode PID set point 0.00–100.00% 0.00
