Chapter 11 Summary of Parameter SettingsCP2000
11-27
Pr. Parameter Name Setting Range Default
only
06-36 IGBT temperature at malfunction -3276.7–3276.7°C
Read
only
06-37
Capacitance temperature at
malfunction
-3276.7–3276.7°C
Read
only
06-38 Motor speed at malfunction -32767–32767 rpm
Read
only
06-40
Status of the multi-function input
terminal at malfunction
0000h–FFFFh
Read
only
06-41
Status of the multi-function output
terminal at malfunction
0000h–FFFFh
Read
only
06-42 Drive status at malfunction 0000h–FFFFh
Read
only
06-44 STO latch selection
0: STO latch
1: STO no latch
0
06-45
Treatment to output phase loss
protection (OPHL)
0: Warn and continue operation
1: Fault and ramp to stop
2: Fault and coast to stop
3: No warning
3
06-46
Detection time of output phase
loss
0.000–65.535 sec. 0.500
06-47
Current detection level for output
phase loss
0.00–100.00% 1.00
06-48
DC brake time of output phase
loss
0.000–65.535 sec. 0.000
06-49 LvX auto-reset
0: Disable
1: Enable
0
06-50
Time for input phase loss
detection
0.00–600.00 sec. 0.20
06-52 Ripple of input phase loss
230V: 0.0–100.0 V
DC
460V: 0.0–200.0 V
DC
575V: 0.0–400.0 V
DC
690V: 0.0–480.0 V
DC
30.0
60.0
75.0
90.0
06-53
Detected input phase loss (OrP)
action
0: Warn and ramp to stop
1: Warn and coast to stop
0
06-55 Derating protection
0: Constant rated current and limit carrier wave by load
current and temperature
1: Constant carrier frequency and limit load current by
setting carrier wave
2: Constant rated current (same as setting 0), but close
current limit
0
06-56 PT100 voltage level 1 0.000–10.000 V 5.000
06-57 PT100 voltage level 2 0.000–10.000 V 7.000
06-58 PT100 level 1 frequency protect 0.00–599.00 Hz 0.00
06-59
PT100 activation level 1 protect
frequency delay time
0–6000 sec. 60
06-60
Software detection GFF current
level
0.0–6553.5% (100% corresponds to the light-load
rated current of the drive)
60.0
