Chapter 11 Summary of Parameter SettingsCP2000
11-26
Pr. Parameter Name Setting Range Default
82: U phase output phase loss (OPHL)
83: V phase output phase loss (OPHL)
84: W phase output phase loss (OPHL)
89: RoPd initial rotor position detection error
90: Inner PLC function is forced to stop
93: CPU error
99: CPU instruction error（TRAP）
101: CANopen software disconnect 1 (CGdE)
102: CAN open software disconnect 2 (CHbE)
103: CANopen synchronous error (CSyE)
104: CANopen hardware disconnect (CbFE)
105: CANopen index setting error (CIdE)
106: CANopen slave station number setting error
(CAdE)
107: CANopen index setting exceed limit (CFrE)
111: ictE Internal communication overtime error
(InerCOM)
142: Auto-tuning error 1 (no feedback current error)
(AUE1)
143: Auto-tuning error 2 (motor phase loss error)
(AUE2)
144: Auto-tuning error 3 (no-load current I
0
measuring
error) (AUE3)
148: Auto-tuning error 4 (leakage inductance Lsigma
measuring error) (AUE4)
06-23 Fault output option 1
0–65535 (refer to bit table for fault code)
0
06-24 Fault output option 2
06-25 Fault output option 3
06-26 Fault output option 4
06-27
Electronic thermal relay selection
2 (Motor 2)
0: Inverter motor (with external forced cooling)
1: Standard motor (motor with fan on the shaft)
2: Disable
2
06-28
Electronic thermal relay action
time 2 (Motor 2)
30.0–600.0 sec. 60.0
06-29
PTC detection selection / PT100
motion
0: Warn and continue operation
1: Fault and ramp to stop
2: Fault and coast to stop
3: No warning
0
06-30 PTC level 0.0–100.0% 50.0
06-31
Frequency command at
malfunction
0.00–599.00 Hz
Read
only
06-32 Output frequency at malfunction 0.00–599.00 Hz
Read
only
06-33 Output voltage at malfunction 0.0–6553.5 V
Read
only
06-34 DC voltage at malfunction 0.0–6553.5 V
Read
only
06-35 Output current at malfunction 0.0–6553.5 Amp Read
