Delta CP2000 Series User Manual

Chapter 12 Description of Parameter SettingsCP2000
12.1-01-3

Mid-point Voltage 2 of Motor 2
Default: 5.0 / 10.0 /
0.0 / 0.0
Settings 230V series: 0.0–240.0 V
460V series: 0.0–480.0 V
575V series: 0.0–637.0 V
690V series: 0.0–720.0 V
690V, 185 kW and above
series: 2.0
Min. Output Frequency of Motor 1
Default: 1.50
Settings 0.00–599.00 Hz

Min. Output Voltage of Motor 1
Default: 1.0 / 2.0 /
0.0 / 0.0
Settings 230V series: 0.0–240.0 V
460V series: 0.0–480.0 V
575V series: 0.0–637.0 V
690V series: 0.0–720.0 V
Min. Output Frequency of Motor 2
Default: 0.50
Settings 0.00–599.00 Hz

Min. Output Voltage of Motor 2
Default: 1.0 / 2.0 /
0.0 / 0.0
Settings 230V series: 0.0–240.0 V
460V series: 0.0–480.0 V
575V series: 0.0–637.0 V
690V series: 0.0–720.0 V
 The V/F curve setting is usually set by the motor’s allowable loading characteristics. If the loading
characteristics exceeds the loading limit of the motor, you must pay more attention to the heat
dissipation, dynamic balance, and bearing lubrication of the motor.
 If the voltage is too high when the motor is at low frequencies, it may cause motor damage,
overheating, and may trigger stalling or over-current protection. To prevent motor damage or
motor fault, be careful when you set the voltage.
 Pr.01-35 to Pr.01-42 is the V/F curve for the motor 2. When multi-function input terminals
Pr.02-01–02-08 and Pr.02-26–Pr.02-31 are set to 14 and enabled, the AC motor drive will act as
the 2
nd
V/F curve.
 The diagram below shows the V/F curve for motor 1. You can also find the V/F curve for motor 2
from the same diagram.

Delta CP2000 Series Specifications

General

Output Voltage	0 ~ Input Voltage
Communication Interface	RS-485
Storage Temperature	-20°C to 60°C
Input Voltage	200-240V AC, 380-480V AC
Protection Functions	Overcurrent, Overvoltage, Undervoltage, Overtemperature, Short Circuit
