Delta CP2000 Series User Manual

Chapter 12 Description of Parameter SettingsCP2000
12.1-02-12
Settings Functions Descriptions
9 Drive is ready Active when the drive is ON with no error detected.
10
Low voltage warning
(Lv)
Active when the DC BUS voltage is too low (refer to Pr.06-00 low
voltage level).
11 Malfunction indication Active when fault occurs (except Lv stop).
12
Mechanical Brake
Release (Pr.02-32)
Active when the drive runs after the set delayed time for Pr.02-32.
This function must use with DC brake function.
13 Over-heat warning
Active when IGBT or heat sink overheats, to prevent the drive from
shutting down due to over-heating (refer to Pr.06-15).
14
Software brake signal
indication
Active when the soft brake function is ON (refer to Pr.07-00).
15 PID feedback error Active when the PID feedback signal error is detected.
16 Slip Error (oSL) Active when the slip error is detected.
17
Count value reached,
does not return to 0
(Pr.02-20)
When the drive executes external counter, this contact is active if the
count value is equal to the setting value for Pr.02-20. This contact is
not active when the setting value for Pr.02-20 > Pr.02-19.
18
Counter value reached,
returns to 0 (Pr. 02-19)
When the drive executes the external counter, this contact is active if
the count value is equal to the setting value for Pr. 02-19.
19
External interrupt B.B.
input (Base Block)
Active when external interrupt (B.B.) stop output occurs in the drive.
20 Warning Output Active when a warning is detected.
21 Over-voltage Active when the over-voltage is detected.
22
Over-current stall
prevention
Active when the over-current stall prevention is detected.
23
Over-voltage stall
prevention
Active when the over-voltage stall prevention is detected.
24
Operation mode
indication
Active when the operation command is controlled by external terminal.
(Pr.00-21≠0)
25 Forward command Active when the operation direction is forward.
26 Reverse command Active when the operation direction is reverse.
27
Output when Current ≥
Pr.02-33
Active when the current is ≥ Pr.02-33.
28
Output when Current <
Pr.02-33
Active when the current is < Pr.02-33
29
Output when frequency
≥ Pr.02-34
Active when the frequency is ≥ Pr.02-34.
30
Output when Frequency
< Pr.02-34
Active when the frequency is < Pr.02-34.
31
Y-connection for the
motor coil
Active when Pr.05-24=1, the frequency output is lower than Pr.05-23
minus 2Hz, and the time is longer than Pr.05-25.
32
∆-connection for the
motor coil
Active when Pr.05-24=1, the frequency output is higher than Pr.05-23
plus 2Hz, and the time is longer than Pr.05-25.
33
Zero Speed (actual
output frequency)
Active when the actual output frequency is 0. (the drive is in RUN
mode)
34
Zero Speed includes
stop (actual output
frequency)
Active when the actual output frequency is 0 or Stopped.
35
Error output selection 1
(Pr.06-23)
Active when Pr.06-23 is ON.
36
Error output selection 2
(Pr.06-24)
Active when Pr.06-24 is ON.

Delta CP2000 Series Specifications

General

Output Voltage	0 ~ Input Voltage
Communication Interface	RS-485
Storage Temperature	-20°C to 60°C
Input Voltage	200-240V AC, 380-480V AC
Protection Functions	Overcurrent, Overvoltage, Undervoltage, Overtemperature, Short Circuit
