Delta CP2000 Series User Manual

Chapter 2 InstallationCP2000
2-6
Air flow rate for cooling Power Dissipation
Model No.
Flow Rate [cfm] Flow Rate [m
3
/hr] Power Dissipation [watt]
External Internal Total External Internal Total
Loss External
(Heat Sink)
Internal Total
VFD1600CP43A-21
VFD1850CP43B-00/
VFD1850CP43B-21
289 112 401 491 190 681 3814 1570 5384
VFD2200CP43A-00/
VFD2200CP43A-21
454 771 6358
VFD2800CP43A-00/
VFD2800CP 43A-21
454 771 7325
VFD3150CP43A-00/
VFD3150CP43C-00/
VFD3150CP43C-21
769 1307 8513
VFD3550CP43A-00/
VFD3550CP43C-00/
VFD3550CP43C-21
769 1307 9440
VFD4000CP43A-00/
VFD4000CP43C-00/
VFD4000CP43C-21
769 1307 10642
VFD5000CP43A-00/
VFD5000CP43C-00/
VFD5000CP43C-21
769 1307 13364
VFD5600CP43A-00/
VFD5600CP43C-21
952.9 1618.9 14350
VFD6300CP43A-00/
VFD6300CP43C-21
952.9 1618.9 16150
VFD015CP53A-21 - - - - - - 39.5 13.0 53
VFD022CP53A-21 - - - - - - 55.0 22.0 77
VFD037CP53A-21 0.006 - 0.006 13.6 - 13.6 86.8 42.7 130
VFD055CP53A-21 0.019 0.007 0.026 40.0 14.5 54.5 124.6 67.9 193
VFD075CP53A-21 0.019 0.007 0.026 40.0 14.5 54.5 143.5 119.0 263
VFD110CP53A-21 0.019 0.007 0.026 40.0 14.5 54.5 222.2 162.8 385
VFD150CP53A-21 0.019 0.007 0.026 40.0 14.5 54.5 308.5 216.5 525
VFD185CP63A-21 90.0 21.3 111.4 153.0 36.2 189.2 317.5 145.0 462.5
VFD220CP63A-21 90.0 21.3 111.4 153.0 36.2 189.2 408.2 141.8 550.0
VFD300CP63A-21 90.0 21.3 111.4 153.0 36.2 189.2 492.7 257.3 750.0
VFD370CP63A-21 89.0 21.3 110.3 151.2 36.2 187.5 641.6 283.4 925.0
VFD450CP63A-00/21 175.9 36.4 212.3 298.8 61.8 360.6 718.2 406.8 1125.0
VFD550CP63A-00/21 175.9 36.4 212.3 298.8 61.8 360.6 890.1 484.9 1375.0
VFD750CP63A-00/21 264.6 90.6 355.2 449.6 153.9 603.5 1356.0 519.0 1875.0
VFD900CP63A-00/21 264.6 90.6 355.2 449.6 153.9 603.5 1652.8 597.2 2250.0
VFD1100CP63A-00/21 264.6 90.6 355.2 449.6 153.9 603.5 1960.3 789.7 2750.0
VFD1320CP63A-00/21 264.6 90.6 355.2 449.6 153.9 603.5 2230.8 1069.2 3300.0
VFD1600CP63A-00/21 248.1 135.3 383.4 421.6 229.9 651.4 2627.3 1372.7 4000.0
VFD2000CP63A-00/21 248.1 135.3 383.4 421.6 229.9 651.4 3415.0 1585.0 5000.0
VFD2500CP63A-00/21 409.7 696.0 4751.7 1498.3 6250.0
VFD3150CP63A-00/21 409.7 696.0 5695.4 2179.6 7875.0
VFD4000CP63A-00/21 563.0 956.4 6796.2 3203.8 10000.0
VFD4500CP63A-00/21 952.9 1618.9 7313.6 3936.4 11250.0
VFD5600CP63A-00/21 952.9 1618.9 9553.4 4446.6 14000.0
VFD6300CP63A-00/21 952.9 1618.9 11042.4 4707.6 15750.0
※ The required airflow shown in chart is for installing single drive in a
confined space.
※ When installing the multiple drives, the required air volume should be the
required air volume for single drive X the number of the drives.
※ The heat dissipation shown in
the chart is for installing single
drive in a confined space.
※ When installing the multiple
drives, volume of heat
dissipation should be the heat
dissipated for single drive X the
number of the drives.
※ Heat dissipation for each model
is calculated by rated voltage,
current and default carrier.
Table 2-3

Delta CP2000 Series Specifications

General

Output Voltage	0 ~ Input Voltage
Communication Interface	RS-485
Storage Temperature	-20°C to 60°C
Input Voltage	200-240V AC, 380-480V AC
Protection Functions	Overcurrent, Overvoltage, Undervoltage, Overtemperature, Short Circuit
