Chapter 12 Description of Parameter SettingsCP2000
12.1-04-1
04 Multi-Step Speed Parameters
This parameter can be set during operation.
1
st
Step Speed Frequency
2
nd
Step Speed Frequency
3
rd
Step Speed Frequency
4
th
Step Speed Frequency
5
th
Step Speed Frequency
6
th
Step Speed Frequency
7
th
Step Speed Frequency
8
th
Step Speed Frequency
9
th
Step Speed Frequency
10
th
Step Speed Frequency
11
th
Step Speed Frequency
12
th
Step Speed Frequency
13
th
Step Speed Frequency
14
th
Step Speed Frequency
15
th
Step Speed Frequency
Default: 0.00
Settings 0.00–599.00 Hz
Use the multi-function input terminals (refer to setting 1–4 of Pr.02-01–Pr.02-08 and
Pr.02-26–Pr.02-31 Multi-function Input Command) to select the multi-step speed command (the
maximum is 15
th
step speed). Pr.04-00 to Pr.04-14 set the multi-step speed frequency as shown
in the following diagram.
The external terminal/digital keypad/communication controls the RUN and STOP commands with
Pr.00-21.
You can set each multi-step speed between 0.00–599.00 Hz during operation.
Explanation for the timing diagram of the multi-step speed and external terminals.
The related parameter settings are:
1. Pr.04-00–04-14: sets the 1
st
to 15
th
multi-step speed (to set the frequency of each step speed)
2. Pr.02-01–02-08 and Pr.02-26–02-31: sets the multi-function input terminals (multi-step speed
command 1–4)
Related parameters:
Pr.01-22 JOG Frequency
Pr.02-01 Multi-function Input Command 1 (MI1)
Pr.02-02 Multi-function Input Command 2 (MI2)
Pr.02-03 Multi-function Input Command 3 (MI3)
Pr.02-04 Multi-function Input Command 4 (MI4)
