Delta CP2000 Series User Manual

Chapter 12 Description of Parameter SettingsCP2000
12.1-07-4
kW 185 220 300 370 450 550 750 900
HP 25 30 40 50 60 75 100 125
Delay time (sec.) 1.1 1.2 1.3 1.4 1.5 1.6 1.7 1.8

Current Limit for Speed Search
Default: 100
Settings 20–200% (100% corresponds to the light-load rated current of the drive)
 The AC motor drive executes speed tracking only if the output current is greater than the value
set in Pr.07-09.

Delta CP2000 Series Specifications

General

Output Voltage	0 ~ Input Voltage
Communication Interface	RS-485
Storage Temperature	-20°C to 60°C
Input Voltage	200-240V AC, 380-480V AC
Protection Functions	Overcurrent, Overvoltage, Undervoltage, Overtemperature, Short Circuit
