Delta CP2000 Series User Manual

Chapter 16 PLC Function Applications│CP2000
16-40
16-5-4 PLC Communication address
Device Range Type Address (Hex)
X 00–37 (Octal) bit 0400–041F
Y 00–37 (Octal) bit 0500–051F
T 00–159 bit/word 0600–069F
M 000–799 bit 0800–0B1F
M 1000–1079 bit 0BE8–0C37
C 0–79 bit/word 0E00–0E47
D 00–399 word 1000–118F
D 1000–1198 word 13E8–144B
D 2000–2799 word 17D0–1AEF
Command code that can be used
Function Code Description of Function Function target
01 Coil status read Y, M, T, C
02 Input status read X,Y,M,T,C
03 Read single unit of data T,C,D
05 Compulsory single coil status change Y,M,T,C
06 Write single unit of data T,C,D
0F Compulsory multiple coil status change Y,M,T,C
10 Write multiple units of data T,C,D
NOTE
When PLC functions have been activated, the CP2000 can match PLC and driver parameters; this method employs
different addresses, drivers (default station number is 1, PLC sets station number as 2)

Delta CP2000 Series Specifications

General

Output Voltage	0 ~ Input Voltage
Communication Interface	RS-485
Storage Temperature	-20°C to 60°C
Input Voltage	200-240V AC, 380-480V AC
Protection Functions	Overcurrent, Overvoltage, Undervoltage, Overtemperature, Short Circuit
