Chapter 5 Main Circuit TerminalsCP2000
5-6
Terminals Descriptions
R/L1, S/L2, T/L3 AC line input terminals 3-phase
U/T1, V/T2, W/T3 AC drive output terminals for connecting 3-phase induction motor
+1, +2
Applicable to frame A–C
Connections for DC reactor to improve the power factor. It needs to remove the
jumper for installation.
+1/DC+, -/DC-
Connections for brake module (VFDB series)
(for 230V models: ≤ 22 kW, built-in brake module)
(for 460V models: ≤ 30 kW, built-in brake module)
(for 690V models: ≤ 37 kW, built-in brake module)
Common DC BUS
B1, B2 Connections for brake resistor (optional)
Earth connection, please comply with local regulations.
Table 5-1
