Delta CP2000 Series User Manual

Chapter 5 Main Circuit TerminalsCP2000
5-12
Frame D0
R/L
1
S/L
2
T
/L3 U/
T
1
V/
T
2
W/
T
3-/DC- +
1
/DC+
 If you install at Ta 40°C environment, please select copper wire with voltage rating 600V and
temperature resistant at 75°C or 90°C.
 If you install at Ta 40°C above environment, please select copper wire with voltage rating 600V and
temperature resistant at 90°C or above.
 For UL installation compliant, please use copper wires for installation, the wire gauge is based on
temperature resistant at 75°C which is requested and recommended from UL. Do not reduce the wire
gauge when using higher temperature wire.
Model Name
Main Circuit Terminals
R/L1, S/L2, T/L3, U/T1, V/T2, W/T3, -/DC-,
+1/DC+
Terminal
Max. Wire
Gauge
Min. Wire Gauge
Screw Spec.
and Torque
(±10%)
Max. Wire
Gauge
Min. Wire
Gauge
Screw Spec.
and Torque
(±10%)
VFD450CP43S-00
70mm
2
[2/0AWG]
50mm
2
[1/0AWG]
M8
80kg-cm
[69.4lb-in.]
[7.84Nm]
35mm
2
[2AWG]
25mm
2
[4AWG]
M8
80kg-cm
[69.4lb-in.]
[7.84Nm]
VFD550CP43S-00 70mm
2
[2/0AWG]
VFD450CP43S-21 50mm
2
[1/0AWG]
VFD550CP43S-21 70mm
2
[2/0AWG]

Delta CP2000 Series Specifications

General

Output Voltage	0 ~ Input Voltage
Communication Interface	RS-485
Storage Temperature	-20°C to 60°C
Input Voltage	200-240V AC, 380-480V AC
Protection Functions	Overcurrent, Overvoltage, Undervoltage, Overtemperature, Short Circuit
