Delta DVP-EX2 User Manual

2. Programming Concepts
2-71
Function Group
ID of right side modules on ES2/EX2/SS2/SA2/SX2/SE
Number
D1320~ D1327
Contents:
When right side modules are connected on ES2/EX2, the ID of each I/O module will be stored in
D1320~D1327 in connection order.
ID of each special module:
Name ID (HEX) Name ID (HEX)
DVP04AD-E2 H’0080 DVP06PT-E2 H’00C2
DVP02DA-E2 H’0041 DVP04TC-E2 H’0083
DVP04DA-E2 H’0081 DVP02PU-E2 H’0045
DVP06XA-E2 H’00C4 DVP10RC-E2 H’0026
DVP04PT-E2 H’0082
When right side modules are connected on SS2/SX2/SA2/SE, the ID of each I/O module will be
stored in D1320~D1327 in connection order.
ID of each special module:
Name ID (HEX) Name ID (HEX) Name ID (HEX)
DVP04AD-S H’0088 DVP06PT-S H’00CA DVP02TUR-S H’034F
DVP02DA-S H’0049 DVP04TC-S H’008B DVP04AD-S2 H’0090
DVP04DA-S H’0089 DVP01PU-S H’0110 DVP04DA-S2 H’0091
DVP06AD-S H’00C8 DVP08NTC-S H’010D DVP06X2-S2 H’00D4
DVP06XA-S H’00CC DVP02TUL-S H’014F
DVP04PT-S H’008A DVP02TUN-S H’024F
Function Group
ID of left side modules on SA2/SX2/SE
Number
D1386~D1393
Contents:
When left side modules are connected on SA2/SX2/SE, the ID of each I/O module will be stored in
D1386~D1393 in connection order. (There is no communication port on left side of DVP28SA2 and
DVP26SE.)
ID of each special module:
Name ID (HEX) Name ID (HEX) Name ID (HEX)
DVP04AD-SL H’4400 DVP01HC-SL H’4120 DVP201LC-SL H’5106
DVP04DA-SL H’4401 DVP02HC-SL H’4220 DVP202LC-SL H’5206
DVP04PT-SL H’4402 DVPDNET-SL H’4131 DVP211LC-SL H’5906
DVP04TC-SL H’4403 DVPEN01-SL H’4050 DVP01LC-SL H’4106
DVP06XA-SL H’6404 DVPMDM-SL H’4040 DVP02LC-SL H’4206
DVP01PU-SL H’4110 DVPCOPM-SL H’4133 DVP02PU-SL H’4207
