DVP-ES2/EX2/EC5/SS2/SA2/SX2/SE&TP Operation Manual - Programming
3-362
 RTU mode (COM3: M1320 = ON, COM1: M1139 = ON):
When X0 = ON, MODRW instruction executes the function specified by Function Code 02
PLC1  PLC2, PLC1 sends: “01 02 0500 0010 79 0A”
PLC2  PLC1, PLC1 receives: “01 02 02 34 12 2F 75”
PLC data receiving register:
Register
Data
Descriptions
D0 1234 H
PLC converts the data in address 0500H ~ 0515H and stores the
converted data automatically.
Analysis of the read status of PLC2 Y0~Y17: 1234H
Device
Status
Device
Status
Device
Status
Device
Status
Y0
OFF
Y1
OFF
Y2
ON
Y3
OFF
Y4
ON
Y5
ON
Y6
OFF
Y7
OFF
Y10
OFF
Y11
On
Y12
OFF
Y13
OFF
Y14
ON
Y15
OFF
Y16
OFF
Y17
OFF
5. Relative flags and data registers when COM1 / COM2 / COM3 works as Master:
COM2
COM1
COM3
Function
COM.
setting
M1120
M1138
M1136
Retain communication setting
M1143
M1139
M1320
ASCII/RTU mode selection
D1120
D1036
D1109
Communication protocol
D1121
D1121
D1255
PLC communication address
Sending
request
M1122
M1312
M1316
Sending request
D1129
D1249
D1252
Set value for data receiving timeout (ms)
Receiving
completed
M1127 M1314 M1318 Data receiving completed
Errors
-
M1315
M1319
Data receiving error
-
D1250
D1253
Communication error code
M1129
-
-
Receiving timeout
M1140
-
-
Data receiving error
M1141 - -
Parameter error. Exception Code is stored in
D1130
D1130 - -
Error code (Exception code) returning from
Modbus communication
