DVP02TK-S/DVP02TU-S Temperature Control Module Manual

2-3

_2

2.1 Control Registers

2.1.1 MODBUS Address List for DVP02TK-S Series

TK MODBUS Address Description

H0000 TK series, CR#0: starting address

H1000 The 1

st

module on the right side of TK series, CR#0: starting address

H2000 The 2

nd

module on the right side of TK series, CR#0: starting address

H3000 The 3

rd

module on the right side of TK series, CR#0: starting address

H4000

The 4

th

module on the right side of TK series, CR#0: starting address

H5000

The 5

th

module on the right side of TK series, CR#0: starting address

H6000

The 6

th

module on the right side of TK series, CR#0: starting address

H7000

The 7

th

module on the right side of TK series, CR#0: starting address

H8000

The 8

th

module on the right side of TK series, CR#0: starting address

Note: Modbus address is required while using Modbus-tk to read-write registers over a RS-485 network.

2.1.2 MODBUS Hex Address List for DVP02TK-S Series

Address

(Hex)

Attribute Name Description Default

0F00 R X

Number of connected

extension modules

Detecting number of the extension modules

connected to the right side of the TK series

--

0F01 R X Code of the 1

st

module

Code of the 1

st

module on the right side of

TK series

--

0F02 R X Code of the 2

nd

module

Code of the 2

nd

module on the right side of

TK series

--

0F03 R X Code of the 3

rd

module

Code of the 3

rd

module on the right side of

TK series

--

0F04 R X Code of the 4

th

module

Code of the 4

th

module on the right side of

TK series

--

0F05 R X

Code of the 5

th

module

Code of the 5

th

module on the right side of

TK series

--

0F06 R X

Code of the 6

th

module

Code of the 6

th

module on the right side of

TK series

--

0F07 R X

Code of the 7

th

module

Code of the 7

th

module on the right side of

TK series

--

0F08 R X

Code of the 8

th

module

Code of the 8

th

module on the right side of

TK series

--

0F09 R/W O RS-485 communication setup

Refer to sections for setting up the RS-485

communication mode

K0

0F0A

R/W

X

Reserved

0F0B R/W O RS-485 communication format

0：ASCII / 1：RTU

K0

0F0C

R/W

O

TK station number

TK station number setup

K1

0F0D R/W X TK operation

0：Stop / 1：Run

--
