Chapter 2 Control Register
2-13
2_
TU
CR#
TK CH1
Page2
Address
Hex
TK CH2
Page12
Address
Hex
Attribute
Name Description Default
max. step number to run
#24
058 138
R/W O
Pattern7_ set up for the
max. step number to run
K0
#25
059 139
R X
The current cycle index
number of the Pattern
number 0~7 to repeat
running
K0
#26
05A 13A
R/W O
Temperature wait function
setup
K0~K999 (unit: 0.1)
K9999: disable
K0
#27
05B 13B
R/W O
Go back to the pattern
number that is currently
running
K0~K7
K0
#28
05C 13C
R/W O
Go back to the step
number that is currently
running
K0
#29
05D 13D
R/W O
Time unit of program
control
K0: The unit is 1 min.
K1: The unit is 0.1 sec.
K0
2.1.7 Pattern0, 1 Setup Page
TU
CR#
TK CH1
Page3
Address
Hex
TK CH2
Page13
Address
Hex
Attribute
Name Description Default
#11
06B 14B
R/W O
Pattern0-0 Target temperature
Range: K -32768~K32767
K0
#12
06C 14C
R/W O
Pattern0-1 Target temperature
#13
06D 14D
R/W O
Pattern0-2 Target temperature
#14
06E 14E
R/W O
Pattern0-3 Target temperature
#15
06F 14F
R/W O
Pattern0-4 Target temperature
#16
070 150
R/W O
Pattern0-5 Target temperature
#17
071 151
R/W O
Pattern0-6 Target temperature
#18
072 152
R/W O
Pattern0-7 Target temperature
#19
073 153
R/W O
Pattern0-0 Running time
Range: K0~K900 Unit
(minutes)
K0
#20
074 154
R/W O
Pattern0-1 Running time
#21
075 155
R/W O
Pattern0-2 Running time
#22
076 156
R/W O
Pattern0-3 Running time
#23
077 157
R/W O
Pattern0-4 Running time
#24
078 158
R/W O
Pattern0-5 Running time
#25
079 159
R/W O
Pattern0-6 Running time
#26
07A 15A
R/W O
Pattern0-7 Running time
