DVP02TK-S/DVP02TU-S Temperature Control Module Manual
2-12
_2
TU
CR#
TK CH1
Page1
Add. (Hex)
TK CH2
Page11
Add. (Hex)
Attribute Name Description Default
#35 043 123 R/W O
Default integral
coefficient
K0~K10000 (The unit is 0.01) K0
#36 044 124 R/W O
Max. value of
MV
K0~K1000 (The unit is 0.1%) K1000
#37 045 125 R/W O
Min value of.
MV
K0~K1000 (The unit is 0.1%) K0
Symbols: O: Latched. X: Non-latched.
R: Able to read data by FROM instruction. W: Able to write data by TO instruction.
2.1.6 Program Control Setup Page
TU
CR#
TK CH1
Page2
Address
（Hex）
TK CH2
Page12
Address
（Hex）
Attribute
Name Description Default
#11
04B 12B
R/W O
Pattern number to start
running
K0~K7 K0
#12
04C 12C
R/W O
Step number to start
running
K0~K7 K0
#13
04D 12D
R/W O
The Cycle index of the
Pattern number 0~7 to
repeat running
K0~K99 indicates the running
times of the Pattern has
reached 100
K9999: running continuously
K0
#14
04E 12E
R X
Read the current running
pattern number
K0~K8 (8 indicates ending) K0
#15
04F 12F
R X
Read the current running
step number
K0~K7 K0
#16
050 130
R X
Read the step running
time left
Unit (seconds) K0
#17
051 131
R/W O
Pattern0_set up for the
max. step number to run
K0~K7 K0
#18
052 132
R/W O
Pattern1_ set up for the
max. step number to run
K0~K7 K0
#19
053 133
R/W O
Pattern2_ set up for the
max. step number to run
K0~K7
K0
#20
054 134
R/W O
Pattern3_ set up for the
max. step number to run
K0
#21
055 135
R/W O
Pattern4_ set up for the
max. step number to run
K0
#22
056 136
R/W O
Pattern5_ set up for the
max. step number to run
K0
#23
057 137
R/W O
Pattern6_ set up for the
K0
