Chapter 2 Control Register
2-11
TU
CR#
TK CH1
Page1
TK CH2
Page11
Attribute Name Description Default
algorithm will be implemented,
otherwise the present error will be
brought into the PID algorithm
according to the normal
#21 035 115
R/W O BIAS
Feedforward output value, used for
the PID feedforward.
K0
#22 036 116
R/W X MV
The MV output value is K0~K1000
and the unit is 0.1.
--
#23 037 117
R/W X
I_MV（Low
word）
Accumulated integral value
temporarily stored is usually for
reference. Users can still clear or
modify it according to their needs.
When the MV is greater than the
MV_MAX, or when the MV is less
than MV_MIN, the accumulated
integral value in I_MV is
--
#24 038 118
R/W X
I_MV（High
word）
--
#25 039 119 R/W O
(PID
hysteresis)
SV - PID Range < PV < SV +
PID Range
K1
K0 ~ K100 and the unit is 0.01.
#27 03B 11B R/W O
point format
(Lo word)
Calculated proportional coefficient
(Kc or Kp)
If the P coefficient is less than 0,
the Kc_Kp will be 0. Independently,
if Kc_Kp is 0, it will not be
1.0
#28 03C 11C R/W O
Kc_Kp floating
point format
(Hi word)
#29 03D 11D R/W O
point format
(Lo word)
Integral coefficient (Ti or Ki）
If the calculated coefficient I is less
than 0, Ti_Ki will be 0. If Ti_Ki is 0,
it will not be controlled by I.
1.0
#30 03E 11E R/W O
point format
#31 03F 11F R/W O
point format
(Lo word)
Derivative coefficient (Td or Kd)
If the calculated coefficient D is less
than 0, Td_Kd will be 0. If Ti_Ki is
0, it will not be controlled by D.
0.1
#32 040 120 R/W O
point format
(Hi word)
#33 041 121 R/W O
format
(Lo word)
Derivate parameter for suppressing
variations can filter derivatives,
which would be more effective with
greater parameter values.
Generally it is suggested to use the
0.0
#34 042 122 R/W O
Tf floating point
format
(Hi word)
To Next Page
