DVP02TK-S/DVP02TU-S Temperature Control Module Manual
2-14
_2
TU
CR#
TK CH1
Page3
Address
（Hex）
TK CH2
Page13
Address
（Hex）
Attribute
Name Description Default
#27
07B 15B
R/W O
Pattern1-0 Target temperature
Range: K-32768~K32767
K0
#28
07C 15C
R/W O
Pattern1-1 Target temperature
#29
07D 15D
R/W O
Pattern1-2 Target temperature
#30
07E 15E
R/W O
Pattern1-3 Target temperature
#31
07F 15F
R/W O
Pattern1-4 Target temperature
#32
080 160
R/W O
Pattern1-5 Target temperature
#33
081 161
R/W O
Pattern1-6 Target temperature
#34
082 162
R/W O
Pattern1-7 Target temperature
#35
083 163
R/W O
Pattern1-0 Running time
Range: K0~K900 (Unit
minutes)
K0
#36
084 164
R/W O
Pattern1-1 Running time
#37
085 165
R/W O
Pattern1-2 Running time
#38
086 166
R/W O
Pattern1-3 Running time
#39
087 167
R/W O
Pattern1-4 Running time
#40
088 168
R/W O
Pattern1-5 Running time
#41
089 169
R/W O
Pattern1-6 Running time
#42
08A 16A
R/W O
Pattern1-7 Running time
2.1.8 Pattern2, 3 Setup Page
TU
CR#
TK CH1
Page4
Address
（Hex）
TK CH2
Page14
Address
（Hex）
Attribute
Name Description Default
#11
08B 16B
R/W O
Pattern2-0 Target temperature
Range: K-32768~K32767
K0
#12
08C 16C
R/W O
Pattern2-1 Target temperature
#13
08D 16D
R/W O
Pattern2-2 Target temperature
#14
08E 16E
R/W O
Pattern2-3 Target temperature
#15
08F 16F
R/W O
Pattern2-4 Target temperature
#16
090 170
R/W O
Pattern2-5 Target temperature
#17
091 171
R/W O
Pattern2-6 Target temperature
#18
092 172
R/W O
Pattern2-7 Target temperature
#19
093 173
R/W O
Pattern2-0 Running time
Range: K0~K900 (Unit
minutes)
K0
#20
094 174
R/W O
Pattern2-1 Running time
#21
095 175
R/W O
Pattern2-2 Running time
#22
096 176
R/W O
Pattern2-3 Running time
#23
097 177
R/W O
Pattern2-4 Running time
#24
098 178
R/W O
Pattern2-5 Running time
#25
099 179
R/W O
Pattern2-6 Running time
#26
09A 17A
R/W O
Pattern2-7 Running time
