DVP02TK-S/DVP02TU-S Temperature Control Module Manual
1-8
_1
1.2.2 DVP02TK-S
8
1
2
3
4
6
7
3.40
60.00
90.00
25.20
60.00
3.00
3.00
3.00
5
9
10
11
Description
1 Run/Error indicator
2 Model name
3 Removable terminal block
4 I/O terminal layout
5 Run/Stop switch
6 I/O module extension port
7 Label
8 DIN rail clip
9 I/O module clip
10 Power connection port
11 RS-485 communication port
