DVP02TK-S/DVP02TU-S Temperature Control Module Manual
2-16
_2
TU
CR#
TK CH1
Page5
Address
（Hex）
TK CH2
Page15
Address
（Hex）
Attribute
Name Description Default
#27
0BB 19B
R/W O
Pattern5-0 Target temperature
Range: K-32768~K32767
K0
#28
0BC 19C
R/W O
Pattern5-1 Target temperature
#29
0BD 19D
R/W O
Pattern5-2 Target temperature
#30
0BE 19E
R/W O
Pattern5-3 Target temperature
#31
0BF 19F
R/W O
Pattern5-4 Target temperature
#32
0C0 1A0
R/W O
Pattern5-5 Target temperature
#33
0C1 1A1
R/W O
Pattern5-6 Target temperature
#34
0C2 1A2
R/W O
Pattern5-7 Target temperature
#35
0C3 1A3
R/W O
Pattern5-0 Running time
Range: K0~K900 (Unit:
minutes)
K0
#36
0C4 1A4
R/W O
Pattern5-1 Running time
#37
0C5 1A5
R/W O
Pattern5-2 Running time
#38
0C6 1A6
R/W O
Pattern5-3 Running time
#39
0C7 1A7
R/W O
Pattern5-4 Running time
#40
0C8 1A8
R/W O
Pattern5-5 Running time
#41
0C9 1A9
R/W O
Pattern5-6 Running time
#42
0CA 1AA
R/W O
Pattern5-7 Running time
2.1.10 Pattern6, 7 Setup Page
TU
CR#
TK CH1
Page6
Address
（Hex）
TK CH2
Page16
Address
（Hex）
Attribute
Name Description Default
#11
0CB 1AB
R/W O
Pattern6-0 Target
temperature
Range: K-32768~K32767
K0
#12
0CC 1AC
R/W O
Pattern6-1 Target
temperature
#13
0CD 1AD
R/W O
Pattern6-2 Target
temperature
#14
0CE 1AE
R/W O
Pattern6-3 Target
temperature
#15
0CF 1AF
R/W O
Pattern6-4 Target
temperature
#16
0D0 1B0
R/W O
Pattern6-5 Target
temperature
#17
0D1 1B1
R/W O
Pattern6-6 Target
temperature
#18
0D2 1B2
R/W O
Pattern6-7 Target
temperature
#19
0D3 1B3
R/W O
Pattern6-0 Running time
Range: K0~K900 (Unit:
K0
