Delta DVP02TK-S User Manual

Chapter 2 Control Register
2-15
2_
TU
CR#
TK CH1
Page4
Address
（Hex）
TK CH2
Page14
Address
（Hex）
Attribute
Name Description Default
#27
09B 17B
R/W O
Pattern3-0 Target temperature
Range: -32768~32767
K0
#28
09C 17C
R/W O
Pattern3-1 Target temperature
#29
09D 17D
R/W O
Pattern3-2 Target temperature
#30
09E 17E
R/W O
Pattern3-3 Target temperature
#31
09F 17F
R/W O
Pattern3-4 Target temperature
#32
0A0 180
R/W O
Pattern3-5 Target temperature
#33
0A1 181
R/W O
Pattern3-6 Target temperature
#34
0A2 182
R/W O
Pattern3-7 Target temperature
#35
0A3 183
R/W O
Pattern3-0 Running time
Range: K0~K900 Unit
(minutes)
K0
#36
0A4 184
R/W O
Pattern3-1 Running time
#37
0A5 185
R/W O
Pattern3-2 Running time
#38
0A6 186
R/W O
Pattern3-3 Running time
#39
0A7 187
R/W O
Pattern3-4 Running time
#40
0A8 188
R/W O
Pattern3-5 Running time
#41
0A9 189
R/W O
Pattern3-6 Running time
#42
0AA 18A
R/W O
Pattern3-7 Running time
2.1.9 Pattern4, 5 Setup Page
TU
CR#
TK CH1
Page5
Address
（Hex）
TK CH2
Page15
Address
（Hex）
Attribute
Name Description Default
#11
0AB 18B
R/W O
Pattern4-0 Target temperature
Range: K-32768~K32767
K0
#12
0AC 18C
R/W O
Pattern4-1 Target temperature
#13
0AD 18D
R/W O
Pattern4-2 Target temperature
#14
0AE 18E
R/W O
Pattern4-3 Target temperature
#15
0AF 18F
R/W O
Pattern4-4 Target temperature
#16
0B0 190
R/W O
Pattern4-5 Target temperature
#17
0B1 191
R/W O
Pattern4-6 Target temperature
#18
0B2 192
R/W O
Pattern4-7 Target temperature
#19
0B3 193
R/W O
Pattern4-0 Running time
Range: K0~K900 (Unit:
minutes)
K0
#20
0B4 194
R/W O
Pattern4-1 Running time
#21
0B5 195
R/W O
Pattern4-2 Running time
#22
0B6 196
R/W O
Pattern4-3 Running time
#23
0B7 197
R/W O
Pattern4-4 Running time
#24
0B8 198
R/W O
Pattern4-5 Running time
#25
0B9 199
R/W O
Pattern4-6 Running time
#26
0BA 19A
R/W O
Pattern4-7 Running time
