Delta DVP02TK-S User Manual

DVP02TK-S/DVP02TU-S Temperature Control Module Manual
2-6
_2
TU
CR#
TK
Add.
(Hex)
Attribute Name Description Default
DVP02TUR-S/DVP02TUN-S/DVP02TKR-S/DVP02
TKN-S：
CR#4 (bit0/bit1): CH1 digital output Y0/Y1
CR#5 (bit0/bit1): CH2 digital output Y2/Y3
#46
24E
R O CH1 display value
The display value is the measured value after being
rounded off or the value set to be displayed for the
channels.
#47
24F
R O CH2 display value
Symbols: O: Latched. X: Non-latched.
R: Able to read data by FROM instruction. W: Able to write data by TO instruction.
 CR#43 Error code descriptions
Error Code
1
0
Bit0 Power Supply abnormal Abnormal Normal
Bit1 Hardware abnormal Abnormal Normal
Bit2 CH1 conversion error Abnormal Normal
Bit3 CH2 conversion error Abnormal Normal
Bit4 CH1 circuit control abnormal Abnormal Normal
Bit5 CH2 circuit control abnormal Abnormal Normal
Bit6 Manually / Auto Output Manually Output Auto Output
Bit7-15 Reserved
2.1.4 Basic Setup Page
TU
CR#
TK CH1
Page0
Add. (Hex)
TK CH2
Page10
Add. (Hex)
Attribute Name Description Default
#11
00B 0EB
R/W O Sensor type
K-255: Channel closed
K0: 0 ~ 5V
K1: 0~10V
K2: 0 ~ 20mA
K3: 4 ~ 20mA
K4: 0 ~ 50mV
K5: Pt100
K6: JPt100
K7: Pt1000
K8: J
K9: K
K10: R
K11: S
K12: T
K13: E
K0
