DVP02TK-S/DVP02TU-S Temperature Control Module Manual
2-20
_2
2.3 Analog Input Description
The analog input value of the CH1 is shown at CR#2, and CH2 at CR#3. Please refer to the following table to set the
input sensor type register. The temperature of the platinum and thermocouple can be set in Celsius or Fahrenheit, unit
0.1 degree. Users can use offset to edit the settings.
Mode Analog Range Digital Range
Current / Voltage
-1
Channel Closed
X
X
0 0~5V 0 ~ 5V
K0 ~ K32000
1 0 ~ 10V 0 ~ 10V
2 0 ~ 20mA 0 ~ 20mA
3
4 ~ 20mA
4 ~ 20mA
4 0 ~ 50mV 0 ~ 50mV
26
0~10V
(Quick AI)
0 ~ 10V
28
-100mV~100mV
-100mV~100mV
K-32000~K32000
29
4 ~ 20mA
(Quick AI)
4 ~ 20mA
K0 ~ K32000
Platinum
5
Pt100
-200 ~ 600°C
K-2000 ~K6000
6 JPt100 -20 ~ 400°C K-200 ~ K4000
7 Pt1000 -200 ~ 600°C K-2000 ~K6000
Thermocouple
8
J
-100 ~ 1200°C
K-1000~K12000
9
K
-200 ~ 1300°C
K-2000~K13000
10 R 0 ~ 1700°C K0 ~K17000
11 S 0 ~ 1700°C K0 ~K17000
12 T -200 ~ 400°C K-2000~K4000
13
E
0 ~ 600°C
K0 ~K6000
14 N -200 ~ 1300°C K-2000~K13000
15 B 100 ~ 1800°C K1000~K18000
16
L
-200 ~ 850°C
K-2000~K8500
17
U
-200 ~ 500°C
K-2000~K5000
18 TXK -200 ~ 800°C K-2000~K8000
19 C 0~1800°C K0~K18000
20
PL II
-100~1370°C
K-1000~K13700
Copper thermal
resistance
21
Cu50
-50~150°C
K-500~K1500
22 Cu100 -50~150°C K-500~K1500
Nickel thermal
resistance
23 Ni100 -100~180°C K-1000~K1800
24
Ni1000
-100~180°C
K-1000~K1800
25
LGNi1000
-60~200°C
K-600~K2000
27 Ni120 -80~260°C K-800~K2600
