EtherCAT Communication Card: CMM-EC02/ CMM-EC03
CMM-EC02/ CMM-EC03 Operation Manual
16

Step1: Remove the
front cover
Step 2: Assemble the connection
cable
Step 3: Assemble the
communication card
Fig 2-26
Fig 2-27
Fig 2-28
Step 4: Tighten the
screws
Step 5: Assemble the
connection cable
Step 6: Assembly
completed
Fig 2-29
Fig 2-30
Fig 2-31
