Delta R2-EC 004 Series User Manual

Product Inspection and Model Explanation R2-ECx004 User Manual
1-2
1
1.1 Product inspection
Check the following after you receive the product.
1. Packaging: check if the shipping carton is intact.
2. Bubble wrap: the bubble wrap is used to protect the product from collision. Check if the
stickers are securely attached to the bubble wrap.
3. R2-ECx004: check if the product appearance is intact.
4. Instruction sheet: check if an instruction sheet is included.
1.2 Model explanation
(1)
E C
-
(3)
(4)
R 2
-
x0
(2)
04
(5)
No.
Item
Description
(1)
Product type
R
Remote I/O series
(2)
Product category
2
Board type (distributed I/O system)
(3)
Bus type
EC
EtherCAT
(4)
Module type
00
Mixed I/O module
10
Input module
20
Output module
(5)
Module subtype
04
24 V
DC
/ 32-CH

Delta R2-EC 004 Series Specifications

General

Brand	Delta
Model	R2-EC 004 Series
Category	Network Hardware
Language	English
